ITEM NO.SBRB1341
NOTE:
This brochure contains IMPORTANT safty info. Please read and keep for future
reference.
01/18

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SBRB1341 and is the answer not in the manual?

Questions and answers

Summary of Contents for HULALA HOME SBRB1341

  • Page 1 HULALA ITEM NO.SBRB1341 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/18...
  • Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soap with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
  • Page 3: Explosive View

    EXPLOSIVE VIEW 2PERSONEN Around 45 min 03/18...
  • Page 4: Parts List

    PARTS LIST 04/18...
  • Page 5: Hardware List

    HARDWARE LIST Ø7*40mm Ø3.5*14mm M6*35mm Ø15*12mm Ø8*30mm M6*50mm Ø4*35mm Ø3.5*30mm TOOL LIST Ø4*14mm Ø8*20mm HARDWARE SPARE LIST Ø7*40mm M6*35mm Ø15*12mm Ø3.5*14mm Ø4*14mm Ø8*30mm 05/18...
  • Page 6 ASSEMBLY INSTRUCTIONS STEP-1 Prepare for part C &E Align the holes in part C&E, tighten #1 with screwdriver #18 . install #6 with screw #5 by screwdriver #18 connect middle foot I with part B #1x2 #1x2 #5x8 #6x4 M6*35mm Ø3.5*14mm 06/18...
  • Page 7 ASSEMBLY INSTRUCTIONS STEP-2 Align the holes in part B, insert wooden dowel #3 by hand Connect the part B with part C&E, insert cam bolt #2 into the corresponding hole of panel B.and tighten the cam bolt #2 with a screwdriver #18 #2X4 #3x4 Ø15*12mm...
  • Page 8 ASSEMBLY INSTRUCTIONS STEP-3 Align the holes in part D, insert wooden dowel #3 by hand Connect the part D&B with screw #4, Align the holes in part F&B,tighten screw #4 with allenkey #19 Align the holes in part J, insert wooden dowel #22 by hand Connect the part J with part C&E,and tighten the screw #16 with a screwdriver #18,.and then stick #17 on the panel C&E accordingly #3x2...
  • Page 9 ASSEMBLY INSTRUCTIONS STEP-4 slide in the part G into the groove in part C,F and F,D and D,F,and F,E . make sure they are also in groove in parB 09/18...
  • Page 10 ASSEMBLY INSTRUCTIONS STEP-5 Prepare for part A. Align the holes in part A, tighten #1 with 。 screwdriver #18 install #6 with screw #5 by screwdriver #18 #1x10 #5x8 #6x4 M6*35mm Ø3.5*14mm 10/18...
  • Page 11 ASSEMBLY INSTRUCTIONS STEP-6 Align the holes in part C&D&E, insert wooden dowel #3 by hand Connect the part A with part C&D&E, insert cam bolt #2 into the corresponding hole of panel C&D&E&F.and tighten the cam bolt #2 with a screwdriver #18 and then stick paster #8 on the corresponding hole of panel C&D&E&F #3x6 #2x10...
  • Page 12 ASSEMBLY INSTRUCTIONS STEP-7 Insert hardware #7 into part G as shown, screw in screw #5 using screwdriver #18 and tighten fully. BACK #5x32 #7x32 Ø3.5*12mm 12/18...
  • Page 13 ASSEMBLY INSTRUCTIONS STEP-8 Insert shelf pin #9 into the holes attach adjustable shelf H to pin #9 #9X8 13/18...
  • Page 14 ASSEMBLY INSTRUCTIONS STEP-9 , Use screw #21 to attach the hinges #10 to door panel (K&N) Use screw #5 to attach the hinges #11 to door panel (L&M), tighten screws #5 with screwdriver #18. , Use screw #5 to attach the hardware #6 to door panel (K&L&M&N) tighten screws #5 with screwdriver #18.
  • Page 15 ASSEMBLY INSTRUCTIONS STEP-10 Make sure the doors (K&L&M&N) are installed as picture show #21x32 Ø4*14mm 15/18...
  • Page 16 ASSEMBLY INSTRUCTIONS STEP-11 Concealed hinges are three-way adjustable: Horizontal by screw adjustment! Concealed hinges are three-way adjustable: In-and-out by loosening the hinge arm mounting screw or via cam adjustment! Concealed hinges are three-way adjustable: Vertical via slots in the mounting plate or via cam adjustment! Hinge adjustment method 16/18...
  • Page 17 ASSEMBLY INSTRUCTIONS STEP-12 Install the anti-collapse device. 2.Mark the position on the wall, that corresponds to the location of part#13 on the panel (A); Drill and insert the expandable screw by hammer. Assemble the part #13 to the wall. Align the hole in the part #13 with the expandable screw #14 , use screw #15 to attach it and tighten by screwdriver #18.
  • Page 18: Warranty

    WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
