  • Page 1 User Manual DS-230 Main Board Module...
  • Page 2 The documentation and the software included with this product are copyrighted 2017 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements in the products described in this manual at any time without notice.
  • Page 3 CHRONTEL is a trademark of Chrontel Inc. All other product names or trademarks are properties of their respective owners. For more information about this and other Advantech products, please visit our web- site at: http://www.advantech.com/ For technical support and service, please visit our support website at: http://support.advantech.com.tw/support/...
  • Page 4 Product Warranty (24 months) Advantech warrants to you, the original purchaser, that each of its products will be free from defects in materials and workmanship for two years from the date of purchase. This warranty does not apply to any products which have been repaired or altered by persons other than repair personnel authorized by Advantech, or which have been subject to misuse, abuse, accident or improper installation.

  • Page 5: Declaration Of Conformity

    - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help.” DS-230 Series User Manual...

  • Page 6: Technical Support And Assistance

    Technical Support and Assistance Visit the Advantech website at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: ...
  • Page 7 DS-230 Series User Manual...
  • Page 8 Remplacez la pile uniquement par le même type ou un type équivalent recommandé par le fabricant. Jetez les piles usagées conformément aux instructions du fabricant. Remarque! Les notes fournissent des informations supplémentaires facultatives. DS-230 Series User Manual...

  • Page 9: Safety Instructions

    CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS. The sound pressure level at the operator's position according to IEC 704-1:1982 is no DS-230 Series User Manual...

  • Page 10: Consignes De Sécurité

    RESTRICTED ACCESS AREA: The equipment should only be installed in a Restricted Access Area. DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. Consignes de sécurité...

  • Page 11: Packing List

    Packing List Before installation, please ensure the following items have been shipped:  1 x DS-230 SDM Module  1 x WiFi antenna kit (depends on configuration)
  • Page 12 Chapter General Introduction This chapter gives background information on DS-230 series DS-230 Series User Manual...

  • Page 13: Product Features

    It also features built-in I/O such as HDMI, mini DP++, USB 3.2, and a single LAN (RJ-45). DS-230 enables media playback and display and is ideal for all-in-one signage applications with space constraints.

  • Page 14: Mechanical Specification

    Operating System: Windows 10 IoT LTSC 2021, Windows 11 IoT LTSC 2024, Linux OS,  Chrome OS SUSI: SUSI is Advantech unique hardware management that provided in standard DS-230  Windows image. Below function are included. Watchdog Timer Hardware Monitor System information ...

  • Page 15: Power Requirements

    Continuous: 12V/5.5A Peak(max 10ms) : 12V/5.5A RTC Battery 1.5.2 BATTERY 3V 195mAH BR2032 1.6 Environmental Specifications Operating 1.6.1 Temperature 0° C - 55°C @0.7m/s air flow 1.6.2 Relative Humidity 95% @ 40°C ( Non Condensing ) DS-230 Series User Manual...
  • Page 16 Vibration Loading During Operation 0.5 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis. 1.6.5 Shock During Vibration 20 G, IEC 60068-2-27, half sine, 11 ms duration 1.6.6 EMC, FCC, VCCI, RCM, UKCA (Class B for all) DS-230 Series User Manual...
  • Page 17 Chapter Hardware configuration This chapter introduces external IO and the installation of DS-230 series Hardware DS-230 Series User Manual...
  • Page 18 Below LED indicator means power on status when it shows green. Figure2.2：Power Below LED indicator means SSD status when it shows yellow. Figure2.3：SSD 2.1.2 Power On/off & Reset button Push below button to power on/off DS-230. Figure2.4：Power Button Push below button to reset DS-230. Figure2.5：Rest Button 2.1.3 DP Below connector is DP connector to let user to connect to esternal display which is with DP interface.
  • Page 19 Figure2.6：DP connector 2.1.4 USB 3.2 connector DS-230 supports 2x USB 3.2 interfaces. The USB interfaces complies withUSB UHCI, Rev. 3.2 standards. Please refer to Table for its pin assignments. USB 3.2 connectors contain legacy pins to interface with USB 2.0 devices, and a new set of pins for USB 3.2 connectivity.
  • Page 20 2.1.5 LAN Connector DS-230 provides one RJ-45 LAN interface connector, fully compliant with IEEE802.3u 10/100/1000/2500 Base-T CSMA/CD standards. The Ethernet port provides a standard RJ- 45 jack connector with LED indicators to show its Active/Link status and speed status. Figure2.9：RJ45 connector...
  • Page 21 2.1.7 Jumpers DS-230 can be configured to satisfy specific application requirements by setting jumpers. A jumper is a metal bridge used to close an electric circuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. To close a jumper, connect the pins with the clip.
  • Page 22 2.1.7.2 Jumper Locations 2.1.7.3 Jumper Settings PSON1 Description AT mode ATX mode (default) JCMOS1 Description Normal operation (default) Clear CMOS DS-230 Series User Manual...
