Advantech PCA-6178 User Manual

Full-size socket 370 intel pentium iii processor-based pci/isa-bus cpu card
Hide thumbs Also See for PCA-6178:
Table of Contents

Advertisement

Quick Links

Download this manual
PCA-6178
®
Full-size socket 370 Intel
®
Pentium
III
processor-based
PCI/ISA-bus CPU card

Advertisement

Table of Contents
loading

Related Manuals for Advantech PCA-6178

Summary of Contents for Advantech PCA-6178

  • Page 1 PCA-6178 ® Full-size socket 370 Intel ® Pentium processor-based PCI/ISA-bus CPU card...

  • Page 2: Copyright Notice

    Copyright notice This document is copyrighted, 2000, by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.

  • Page 3: Technical Support

    A Message to the Customer Advantech customer services Each and every Advantech product is built to the most exacting specifications to ensure reliable performance in the harsh and demanding conditions typical of industrial environments. Whether your new Advantech equipment is destined for the laboratory or the...
  • Page 4 ® ® l e t u i t / I I I r e l ™ ® l e t & ) s t d i l s t r ® l a i e l l ™ ® n I ( l e t ) t e t i b...
  • Page 5 t n I ® ® / I I I ™ ® t n I & ® ™ ® t n I...

  • Page 6: Product Warranty

    Advantech assumes no liability under the terms of this warranty as a consequence of such events. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.

  • Page 7: Initial Inspection

    It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the PCA-6178, check it for signs of shipping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifications, notify our service department or your local sales representative immediately.

  • Page 8: Table Of Contents

    Contents Chapter 1 Hardware Configuration ......1 Introduction ................2 Features ................3 Specifications ..............5 1.3.1 System .................5 1.3.2 Memory ...............5 1.3.3 Input/Output ..............6 1.3.4 VGA interface .............6 1.3.5 SCSI interface .............6 1.3.6 Ethernet LAN (PCA-6178E/6168F only) ....6 1.3.7 Solid state disk ............6 1.3.7 Industrial features ............7 1.3.8 Mechanical and environmental specifications ....7 Board Layout: Main Features ..........8...
  • Page 9 Chapter 2 Connecting Peripherals ......23 Primary (CN1) and Secondary (CN2) IDE Connectors24 Floppy Drive Connector (CN3) ........25 Parallel Port (CN4) ............25 SCSI Connector (CN5) ............26 USB Port (CN6) ..............27 VGA Connector (CN7) ............27 10/100Base-T Ethernet Connector (CN8) ......28 Serial Ports (CN9: COM1; CN10: COM2) ....28 PS/2 Keyboard and Mouse Connector (CN11) .....29 2.10 External Keyboard Connector (CN12) ......29 2.11 Infrared (IR) Connector (CN13) ........30...
  • Page 10 3.4.4 Boot Up Floppy Seek ..........40 3.4.5 Boot Up NumLock Status .........40 3.4.6 Gate A20 Option ............40 3.4.7 Typematic Rate Setting ..........40 3.4.8 Typematic Rate (Chars/Sec) ........40 3.4.9 Typematic Delay (msec) ........... 41 3.4.10 Security Option ............41 3.4.11 PCI/VGA Palette Snoop.......... 41 3.4.12 OS Select for DRAM >...
  • Page 11 3.10.5 Onboard Serial Port 1 (3F8H/IRQ4) .......48 3.10.6 Onboard Serial Port 2 (2F8H/IRQ3) .......48 3.10.7 Onboard Parallel Port (378H/IRQ7) .......48 3.10.8 Parallel Port Mode (ECP + EPP) ......48 3.10.9 ECP Mode Use DMA ..........48 3.11 Password Setting ..............49 3.12 IDE HDD Auto Detection ..........49 3.13 Save &...
  • Page 12 Configuring the SCSI Adapter ........83 SCSI Terminators ............84 SDMS Drivers ..............85 Chapter 7 Onboard Security Setup ......87 Introduction ..............88 Driver Installation ............88 7.2.1 Before you begin ............88 7.2.2 Windows 95 drivers setup procedure ......89 Windows NT driver setup procedure ......98 Appendix A Programming the Watchdog Timer ..
  • Page 13 B.21 1st MB Memory Map.............120 B.22 PCI Bus Map ..............120 Appendix C DiskOnChip® 2000 Installation Guide 121 DiskOnChip® 2000 Quick Installation Guide ....122 C.1.1 DiskOnChip® 2000 installation instructions ..122 C.1.2 Addtional information and assistance ....123...
  • Page 14 Tables Table 1-1: Jumpers ......................9 Table 1-2: Connectors ....................10 Table 1-3: CPU clock ratio setting (SW1) ..............14 Table 1-4: CPU type select (SW2) ................. 14 Table 1-5: CMOS clear (J1) ................... 15 Table 1-6: Watchdog timer output (J2) ................15 Table 1-7: DiskOnChip®...
  • Page 15 Figures Figure 1-1: Board layout: main features ............... 8 Figure 1-2: Board layout: jumper and connecter locations ......... 11 Figure 1-3: DIMM installation ..................20 Figure 7-2: Setup under Win95 ................... 90 Figure 7-3: Restarting Windows ................. 90...

  • Page 16: Chapter 1 Hardware Configuration

    Hardware Configuration This chapter gives background informa- tion on the PCA-6178. It then shows you how to configure the card to match your application and prepare it for installation into your PC. Sections include: • Introduction • Features • Specifications •...

  • Page 17: Introduction

    VGA (AGP) controller, a PCI Ultra2 SCSI controller, a 10/100Base-T networking controller, three DIMM slots for a total of 768 MB RAM memory, and an ISA High Drive. In addition, the PCA-6178 Series supports a solid state disk (SSD) using M-Systems Corporation's ®...

  • Page 18: Features

    Features 1. Fan status monitoring and alarm: To prevent system overheat- ing and damage, the CPU fan can be monitored for speed and failure. The fan is set for its normal RPM range, and alarm thresholds. 2. Temperature monitoring and alert: To prevent system overheat- ing and damage, the CPU card supports processor thermal sensing and auto-protection.
  • Page 19 In this case, a warning message will be displayed. You can then run your anti-virus program to locate the problem PCA-6178 User's Manual...

  • Page 20: Specifications

    Specifications 1.3.1 System ® • CPU: Intel Pentium III /Celeron™ processor, up to 850+ MHz • BIOS: Award Flash BIOS, 2 Mb • Green function: Supports power management operation via BIOS. Activated by keyboard or mouse activity • PCI enhanced IDE hard disk drive interface: Supports up to four IDE (AT-bus) large hard disk drives or other enhanced IDE devices.

  • Page 21: Input/Output

    80 MB/sec. • Chipset: Symbios SYM53C895 1.3.6 Ethernet LAN (PCA-6178E/6178F only) • Supports 10/100Base-T Ethernet networking • Chipset: Intel 82559 1.3.7 Solid state disk ® • Supports DOC 2000 up to 144 MB PCA-6178 User's Manual...

  • Page 22: Industrial Features

    1.3.7 Industrial features • Watchdog timer: Can generate a system reset or IRQ11. The watchdog timer is programmable, with each unit equal to one second (63 levels). The program uses I/O port hex 443h to control the watchdog timer 1.3.8 Mechanical and environmental specifications •...

  • Page 23: Board Layout: Main Features

    Board Layout: Main Features Figure 1-1: Board layout: main features PCA-6178 User's Manual...

  • Page 24: Jumpers And Connectors

    Jumpers and Connectors Connectors on the PCA-6178 board link it to external devices such as hard disk drives and a keyboard. In addition, the board has a number of jumpers used to configure your system for your application. The tables below list the function of each of the board jumpers and connectors.

  • Page 25: Table 1-2: Connectors

    CPU fan connector CN16 Keyboard lock and power LED CN17 External speaker CN18 Reset connector CN19 HDD LED connector CN20 ATX feature connector CN21 ATX soft power switch CN22 Reserved (Default closed) CN26 VGA feature connector (Reserved) PCA-6178 User's Manual...

  • Page 26: Board Layout: Jumper And Connector Locations

    Board Layout: Jumper and Connector Locations Figure 1-2: Board layout: jumper and connecter locations Chapter 1 Hardware Configuration...

  • Page 27: Safety Precautions

    As a safety precaution, use a grounding wrist strap at all times. Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. PCA-6178 User's Manual...

  • Page 28: Jumper Settings

    1 and 2, or 2 and 3. A pair of needle-nose pliers may be useful when setting jumpers. 1.8.2 CPU clock ratio setting (SW1) You must configure your PCA-6178 CPU card to the frequency of your ® Intel Celeron™/Coppermine processor by setting jumper SW1.

  • Page 29: Cpu Type Select (Sw2)

    Table 1-3: CPU clock ratio setting (SW1) Ratio SW1-1 SW1-2 SW1-3 SW1-4 1.8.3 CPU type select (SW2) Table 1-4: CPU type select (SW2) CPU type SW2-1 SW2-2 Celeron™ Coppermine PCA-6178 User's Manual...

  • Page 30: Cmos Clear (J1)

    1.8.4 CMOS clear (J1) The PCA-6178 CPU card contains a jumper that can erase CMOS data and reset the system BIOS information. Normally this jumper should be set with pins 1-2 closed. If you want to reset the CMOS data, set J1 to 2-3 closed for just a few seconds, and then move the jumper back to 1-2 closed.

  • Page 31: Diskonchip 2000 Flash Disk Address Select (J3)

    1.8.6 DiskOnChip 2000 Flash disk address select (J3) ® The PCA-6178 includes a 32-pin socket for M-Systems' DiskOnChip 2000 Flash disk module. This revolutionary solid state disk enables critical system information to be stored within an on-board Flash disk for virtually instantaneous data access.
  • Page 32 ® Table 1-7: DiskOnChip 2000 Flash disk memory address jumper settings (J3) Segment C800h CC00h D000h D400h D800h DC00h E000h Disable Chapter 1 Hardware Configuration...

  • Page 33: System Memory

    (16, 32, 64, 128 or 256 MB) x 1 1.9.1 Sample calculation: DIMM memory capacity Suppose you install a 128 MB DIMM into your PCA-6178's socket 1 and a 32 MB DIMM into sockets 2 and 3. Your total system memory...

  • Page 34: Supplementary Information About Dimms

    Your PCA-6178 can accept SDRAM memory chips (with or without parity). Also note: • If the PCA-6178 operates at 100 MHz, only use PC-100/ PC-133- compliant DIMMs. Most systems will not even boot if non-compli- ant modules are used. This is due to strict timing issues involved at this speed.

  • Page 35: Memory Installation Procedures

    Celeron™/Coppermine processor, you do not have to take care of either SRAM chips or SRAM modules. The built-in second level cache in the Celeron/Coppermine processor yields much higher performance ® than the external cache memories. The cache size in the Intel Celeron™/Coppermine processor is 128/256 KB. PCA-6178 User's Manual...

  • Page 36: Cpu Installation

    1.12 CPU Installation ® ® The PCA-6178 provides a socket 370 for an Intel Pentium III/ Celeron™processor. The CPU on the board must have a fan or heat sink attached, to prevent overheating. Warning: Without a fan or heat sink, the CPU will overheat and cause damage to both the CPU and the mother- board.
  • Page 37 PCA-6178 User's Manual...

  • Page 38: Chapter 2 Connecting Peripherals

    Connecting Peripherals This chapter tells how to connect periph- erals, switches and indicators to the PCA-6178 board. You can access most of the connectors from the top of the board while it is installed in the chassis. If you have a number of cards installed, or your...
  • Page 39 Connectors You can attach up to four IDE (Integrated Device Electronics) drives to the PCA-6178’s internal controller. The primary (CN1) and secondary (CN2) connectors can each accommodate two drives. Wire number 1 on the cable is red or blue and the other wires are gray.

  • Page 40: Floppy Drive Connector (Cn3)

    Floppy Drive Connector (CN3) You can attach up to two floppy disk drives to the PCA-6178's onboard controller. You can use any combination of 5.25" (360 KB / 1.2 MB) and/or 3.5" (720 KB / 1.44/2.88 MB) drives. The card comes with a 34-pin daisy-chain drive connector cable. On one end of the cable is a 34-pin flat-cable connector.

  • Page 41: Scsi Connector (Cn5)

    Make sure that wire 1 corresponds to pin 1 of CN4. Pin 1 is on the upper right side of CN4. SCSI Connector (CN5) The PCA-6178 has a 68-pin, dual in-line connector for Ultra2 SCSI devices. Connection of SCSI devices requires special attention, especially when determining the last drive on the SCSI chain. Refer to Chapter 6 and your device's operating manual for detailed installation advice.

  • Page 42: Usb Port (Cn6)

    The USB interface can be disabled in the system BIOS setup. VGA Connector (CN7) The PCA-6178 includes a PCI SVGA interface that can drive conven- tional CRT displays. CN7 is a standard 15-pin D-SUB connector commonly used for VGA. Pin assignments for CRT connector CN7 are detailed in Appendix B.

  • Page 43: 10/100Base-T Ethernet Connector (Cn8)

    Serial Ports (CN9: COM1; CN10: COM2) C N 9 The PCA-6178 offers two serial ports, CN9 as COM1 and CN10 as COM2. These ports can connect to serial devices (such as a mouse, printers, and so on) or to a communication network.

  • Page 44: Ps/2 Keyboard And Mouse Connector (Cn11)

    PS/2 Keyboard and Mouse Connector (CN11) CN11 The PCA-6178 board provides a keyboard connector. A 6-pin mini-DIN connector (CN11) on the card mounting bracket supports single-board computer applications. The card comes with an adapter to convert from the 6-pin mini-DIN connector to a standard DIN connector and to a PS/2 mouse connector.

  • Page 45: Infrared (Ir) Connector (Cn13)

    2.11 Infrared (IR) Connector (CN13) CN13 This connector supports the optional wireless infrared transmitting and receiving module. This module mounts on the system case. You must configure the setting through the BIOS setup (see Chapter 3). 2.12 CPU Fan Connector (CN14) CN14 This connector supports cooling fans of 500 mA (6 W) or less.

  • Page 46: Front Panel Connectors (Cn16, Cn17, Cn18, Cn19 And Cn21)

    2.13.2 External speaker (CN17) CN17 is a 4-pin connector for an extenal speaker. If there is no external speaker, the PCA-6178 provides an on-board buzzer as an alternative. To enable the buzzer, set pins 3-4 as closed. 2.13.3 Reset (CN18) Many computer cases offer the convenience of a reset button.

  • Page 47: Hdd Led (Cn19)

    CN21. 2.14.1 ATX feature connector (CN20) and soft power switch connector (CN21) The PCA-6178 can support an advanced soft power switch function if an ATX power supply is used. To enable the soft power switch function: 1. Take the specially designed ATX-to-PS/2 power cable out of the PCA-6178's accessory bag.

  • Page 48: Controlling The Soft Power Switch

    Warnings: 1. Make sure that you unplug your power supply when adding or removing expansion cards or other system components. Failure to do so may cause severe damage to both your CPU card and expan- sion cards. 2. ATX power supplies may power on if certain motherboard components or connections are touched by metallic objects.
  • Page 49 PCA-6168 User's Manual...

  • Page 50: Chapter 3 Award Bios Setup

    Award BIOS Setup This chapter describes how to set the card’s BIOS configuration data.

  • Page 51: Introduction

    CPU. If there is no number assigned to the patch code, please contact Advantech’s applications engineer to obtain an up-to-date patch code file. This will ensure that your CPU’s system status is valid. After ensuring that you have a number assigned to the patch code, press <Del>...

  • Page 52: Standard Cmos Setup

    Standard CMOS Setup Choose the “STANDARD CMOS SETUP” option from the “INITIAL SETUP SCREEN” menu, and the screen below will be displayed. This standard setup menu allows users to configure system components such as date, time, hard disk drive, floppy drive, display, and memory. Base Memory = 640K Extended Memory = 130048K Other Memory = 384K...

  • Page 53: Bios Features Setup

    The “BIOS FEATURES SETUP” screen appears when choosing the “BIOS FEATURES SETUP” item from the “CMOS SETUP UTILITY” menu. It allows the user to configure the PCA-6178 accord- ing to his particular requirements. Below are some major items that are provided in the BIOS FEATURES SETUP screen.

  • Page 54: Quick Power On Self Test

    3.4.2 Quick Power On Self Test This option speeds up the Power-On Self Test (POST) conducted as soon as the computer is turned on. When enabled, BIOS shortens or skips some of the items during the test. When disabled, the computer conducts normal POST procedures.

  • Page 55: Boot Up Floppy Seek

    The typematic rate determines the characters per second accepted by the computer. Typematic Rate Setting enables or disables the typemat- ic rate. 3.4.8 Typematic Rate (Chars/Sec) BIOS accepts the following input values (characters/second) for typematic rate: 6, 8, 10, 12, 15, 20, 24, 30. PCA-6178 User’s Manual...

  • Page 56: Typematic Delay (Msec)

    3.4.9 Typematic Delay (msec) Typematic delay is the time interval between the appearance of two consecutive characters, when holding down a key. The input values for this category are: 250, 500, 750, 1000 (msec). 3.4.10 Security Option This setting determines whether the system will boot up if the password is denied.

  • Page 57: C8000-Cbfff Shadow / Dc000-Dffff Shadow

    If you enable the OBS function, you can view the temperature, fan speed and voltage of your PC system. The data will be displayed in similar fashion to the display shown in Fig. 3-4: Figure 3-4: Chipset features setup screen PCA-6178 User’s Manual...

  • Page 58: Sdram Ras To Cas Delay

    3.5.1 SDRAM RAS to CAS Delay This controls the latency between SDRAM active command and the read/write command. Leave this on the default setting. 3.5.2 SDRAM RAS Precharge Time This controls the idle clocks after issuing a precharge command to SDRAM.

  • Page 59: Agp Aperture Size (Mb)

    You can choose to turn the HDD off after one of the time intervals listed, or when the system is in “suspend” mode. If the HDD is in a power saving mode, any access to it will wake it up. PCA-6178 User’s Manual...

  • Page 60: Soft-Off By Pwr-Bttn

    Note: The HDD will not power down if the Power Management option is disabled. 3.6.3 Soft-Off by PWR-BTTN If you choose “Instant-Off”, then pushing the ATX soft power switch button once will switch the system to “system off” power mode. You can choose “Delay 4 sec.”...

  • Page 61: Dma-X Assigned To : Pci/Isa Pnp

    These default values are loaded automatically if the stored record created by the setup program becomes corrupted (and therefore unusable). Load Setup Defaults “LOAD SETUP DEFAULTS” loads the values required by the system for maximum performance. PCA-6178 User’s Manual...

  • Page 62: Integrated Peripherals

    3.10 Integrated Peripherals Figure 3-7: Integrated peripherals 3.10.1 IDE HDD Block Mode If you enable IDE HDD Block Mode, the enhanced IDE driver will be enabled. Leave IDE HDD Block Mode on the default setting. 3.10.2 IDE Primary Master/Slave PIO/UDMA Mode, IDE Secondary Master/Slave PIO/UDMA Mode (Auto) Each channel (Primary and Secondary) has both a master and a slave, making four IDE devices possible.

  • Page 63: Onboard Fdc Controller

    This selection is available only if you select “ECP” or “ECP + EPP” in the Parallel Port Mode field. In ECP Mode Use DMA, you can select DMA channel 1, DMA channel 3, or Disable. Leave this field on the default setting. PCA-6178 User’s Manual...

  • Page 64: Password Setting

    3.11 Password Setting To change the password: 1. Choose the “PASSWORD SETTING” option from the Setup main menu and press <Enter>. The screen will display the following message: Enter Password: Press <Enter>. 2. If the CMOS is good or if this option has been used to change the default password, the user is asked for the password stored in the CMOS.

  • Page 65: Save & Exit Setup

    This record is required for the system to operate. 3.14 Exit Without Saving Selecting this option and pressing <Enter> lets you exit the setup program without recording any new values or changing old ones. PCA-6178 User’s Manual...

  • Page 66: Chapter 4 Pci Svga Setup

    PCI SVGA Setup The PCA-6178 features an onboard PCI AGP/VGA interface. This chapter provides instructions for installing and operating the software drivers on the display driver CD included in your package.

  • Page 67: Before You Begin

    The enhanced display drivers for the PCA-6178 board are located on the software installation CD. You must install the drivers and utility software by using the supplied SETUP program for DOS drivers.

  • Page 68: Installation

    • User-friendly installation for Windows 95 and Windows NT • AGP 1.0 interface • 4 MB/ 8 MB, 64-bit, 100 MHz SGRAM frame buffer interface with 800 MB/sec bus bandwidth • Integrates superior video features. These include filtered sealing of 720 pixel DVD content, and MPEG-2 motion compensation for software DVD Installation...
  • Page 69 Click on the right driver for the installation PCA-6178 User's Manual...

  • Page 70: Driver Installation

    Driver Installation 4.4.1 Necessary prerequisites The instructions in this manual assume that you understand elementa- ry concepts of MS-DOS and the IBM personal computer. Before you attempt to install any driver or utility, you should know how to copy files from a floppy disk to a directory on the hard disk. You should also understand the MS-DOS directory structure, and know how to format a floppy disk.

  • Page 71: Windows 95/98 Drivers Setup Procedure

    Windows 95/98 Drivers Setup Proce- dure 1. Insert the CD and click on PCA-6178B. Click Win 9x PCA-6178 User's Manual...
  • Page 72 2. Click "Finish" 3. Start the installation Chapter 4 PCI SVGA Setup...

  • Page 73: Windows Nt Drivers Setup Procedure

    Windows NT Drivers Setup Procedure Note: Before you install the VGA driver, make sure that you are using service pack 3 (or above). 1. Click on " WIN NT". 2. Click "Next". PCA-6178 User's Manual...
  • Page 74 3. Click "Finish" to restart your computer and enable the changes to take effect. Chapter 4 PCI SVGA Setup...
  • Page 75 PCA-6178 User's Manual...

  • Page 76: Chapter 5 Lan Configuration

    LAN Configuration The PCA-6178 features an onboard LAN interface. This chapter gives detailed information on Ethernet configuration. It shows you how to configure the card to match your application requirements. Sections include:...

  • Page 77: Introduction

    5.1 Introduction The PCA-6178 features an optional 32-bit 10/100 Mbps Ethernet network interface. This interface supports bus mastering architecture and auto-negotiation features. Therefore standard twisted-pair cabling with RJ-45 connectors for both 10 Mbps and 100 Mbps connections can be used. Extensive driver support for commonly-used network systems is also provided.

  • Page 78: Driver Installation

    5.3 Driver Installation The PCA-6178's onboard Ethernet interface supports all major network operating systems. The BIOS automatically detects the LAN while booting, and assigns an IRQ level and I/O address. No jumpers or switches are required for user configuration. The drivers and installation instructions are located in the following directories of the utility CD: •...

  • Page 79: Windows 95/98/98Se Drivers Setup Procedure

    Note 2: The CD-ROM drive is designated as "D" throughout this section. 1. In the "Windows 98" screen, click on "Start" and select "Set- tings". Then click on the "Control Panel" icon to select "System". PCA-6178 User's Manual...
  • Page 80 2. In the "System Properties" window, select the "Device Manager" tab. Select "View devices by type", and navigate to: Computer\Other devices\Intel[R] PRO/100+ Management Adapter. Highlight "Intel[R] PRO/100+ Management Adapter" and click on "Properties". Chapter 5 LAN Configuration...
  • Page 81 3. In the "Intel[R] PRO/100+ Management Adapter Properties" window, select the "Driver" tab. Then click on "Update Driver...". 4. In the "Update Device Driver Wizard" window, click on "Next". PCA-6178 User's Manual...
  • Page 82 5. In the following "Update Device Driver Wizard" window, select "Specify a location:". Type in: "D:\PCA6178\LAN". Then click on "Next". Chapter 5 LAN Configuration...
  • Page 83 6. In the following "Update Device Driver Wizard" window, select "The updated driver ...". Then click on "Next". 7. In the following "Update Device Driver Wizard" window, click on "Next". PCA-6178 User's Manual...
  • Page 84 8. In the "Copying Files..." window, the correct file path should be: D:\PCA6178\LAN. When you have the correct location, click on "OK". 9. When the "Insert Disk" window appears, insert the utility CD into the CD-ROM drive. Then click on "OK". Chapter 5 LAN Configuration...
  • Page 85 10. When the "Update Device Driver Wizard" window, click on "Finish". 11. In the "System Settings Change" window, click on "Yes". PCA-6178 User's Manual...

  • Page 86: Windows Nt Drivers Setup Procedure

    5.5 Windows NT Drivers Setup Procedure Note: The CD-ROM drive is designated as "D" throughout this section. 1. In the "Windows NT" screen, click on "Start" and select "Set- tings". Then click on the "Control Panel" icon to select "Net- work".
  • Page 87 3. In the "Select Network Adapter" window, click on "Have Disk...". 4. When the "Insert Disk" window appears, insert the utility CD into the CD-ROM drive. The correct file path is; D:\PCA6178\LAN. When you have the correct file path, click on "OK". PCA-6178 User's Manual...
  • Page 88 5. In the "Select OEM Option" window, click on "OK". 6. In the "Network" window, select the "Adapters" tab. Under "Network Adapters:", highlight "[2] Intel[R] PRO/100+ Manage- ment Adapter". Then click on "Close". Chapter 5 LAN Configuration...
  • Page 89 7. In the "Microsoft TCP/IP Properties" window, select the "IP Address" tab. Then select "Specify an IP address". Type in the IP Address and Subnet Mask details. Then click on "OK". 8. In the "Network Settings Change" window, click on "Yes". PCA-6178 User's Manual...
  • Page 90 9. You are now ready to enable the LAN device driver. In the "Windows NT" screen, click on "Start" and select "Settings". Then click on the "Control Panel" icon to select "Network". 10. In the "Network" window, select the "Adapters" tab. Under "Network Adapters:", highlight "[2] Intel[R] PRO/100+ Manage- ment Adapter".

  • Page 91: Windows Nt Wake-On-Lan Setup Procedure

    5.6 Windows NT Wake-on-LAN Setup Procedure 1. In the "Windows NT" screen, click on "Start" and select "Set- tings". Then click on the "Control Panel" icon to select "System". PCA-6178 User's Manual...
  • Page 92 2. In the "Intel[R] PROSet" window, under "Select a Network Adapter", choose "[2] Intel[R] PRO100+ Management Adapter". The select the "Advanced" tab. Under "Setting", highlight the "Enable PME" item. Under "Value", select "Enabled". Then click on "OK". 3. In the "Reboot Required" window, click on "Yes". Chapter 5 LAN Configuration...
  • Page 93 PCA-6178 User's Manual...

  • Page 94: Chapter 6 Scsi Setup And Configurations

    SCSI Setup and Configurations The PCA-6178 features an onboard SCSI interface. This chapter provides basic SCSI concepts and instructions for installing the software drivers with the SCSI driver disks/CD included in your package.

  • Page 95: Introduction

    Introduction The PCA-6178 is equipped with a Symbios SYM53C895 single-chip PCI-to-SCSI host adapter which provides a powerful Ultra2 multitask- ing interface between your computer’s PCI bus and SCSI devices (disk drives, CD-ROM drives, scanners, tape backups, removable media drives, etc.). Up to a total of 15 SCSI devices can be connected to the SCSI connector through the Symbios SYM53C895.

  • Page 96: Basic Rules For Scsi Host Adapter And Device

    Basic Rules for SCSI Host Adapter and Device Installation You must terminate both ends of the SCSI bus. Refer to the hardware manuals for the devices and the host adapter to properly terminate the bus. Unless your system is SCSI Configured AutoMatically (SCAM) capable, you must configure each SCSI device with a different SCSI ID number.

  • Page 97: Scsi Terminators

    Proper termination for internal Ultra2 peripherals is provided by the built-in terminator at the end of the Ultra2 internal SCSI cable. • Most non-Ultra2 SCSI peripherals come from the factory with termination enabled. PCA-6178 User’s Manual...

  • Page 98: Sdms Drivers

    SDMS Drivers The SDMS device drivers translate an operating system I/O request into a SCSI request. Each Symbios SCSI device driver is operating system specific and is designed to work on standard Symbios chip implementations. We provide PCI SDMS device drivers for the following operating systems: •...
  • Page 99 PCA-6178 User’s Manual...

  • Page 100: Chapter 7 Onboard Security Setup

    Onboard Security Setup This chapter explains OBS concepts and provides instructions for installing the relevant software drivers. This is done using the OBS driver CD included in your PCA-6178 package.

  • Page 101: Introduction

    Introduction Onboard security (OBS) functions monitor key hardware. They help you maintain your system's stability and durability. The PCA-6178 can monitor 5 sets of system positive voltages, 2 sets of system negative voltages, CPU cooling fan speed, and CPU temperature.

  • Page 102: Windows 95 Drivers Setup Procedure

    7.2.2 Windows 95 drivers setup procedure 1. Insert drivers CD, click on OBS icon Chapter 7 Onboard Security Setup...
  • Page 103 2. If your operating system is Win95, you will see the following screen images after running the driver. You must then reboot your system, start the procedure from Step 1 again, and then proceed directly to Step 3. PCA-6178 User's Manual...
  • Page 104 Follow the screen instructions to install the software. Chapter 7 Onboard Security Setup...

  • Page 105: Figure 7-2: Setup Under Win95

    3. Choose the Directory you want to install the files to. 4. Let the installation continue, and complete the setup. PCA-6178 User's Manual...
  • Page 106 5. Using your file manager, click on "Hardware Doctor" in drive C:, and then click on W83781". Chapter 7 Onboard Security Setup...
  • Page 107 6. It is recommended that you load the default values for all the OBS settings. However, if desired, you can establish new conditions for voltage, fan speed and temperature. PCA-6178 User's Manual...
  • Page 108 7. "Winbond Hardware Doctor" will show an icon on the right side of the bottom window bar. This icon is the "Terminate and Stay Resident" (TSR) icon. It will permanently remain in the bottom window bar, and will activate warning signals when triggered by the onboard security system.
  • Page 109 "Count 3". This will result in a warning message being delivered only after any monitored reading exceeds safe limits for a third time. It is recommended that you load the default settings for all the OBS functions. PCA-6178 User's Manual...
  • Page 110 9. After completing the setup, all the OBS functions are permanently enabled. When a monitored reading exceeds safe limits, a warning message will be displayed and an error beep tone will activate to attract your attention. Chapter 7 Onboard Security Setup...

  • Page 111: Windows Nt Driver Setup Procedure

    Windows NT driver setup procedure Insert driver CD to start the NT driver setup 1. Click "Next". PCA-6178 User's Manual...
  • Page 112 2. Click "Next". 3. Click "Next". Chapter 7 Onboard Security Setup...
  • Page 113 4. Start the installation. 5. Finish the set up. PCA-6178 User's Manual...
  • Page 114 6. Click "OK" to restart the computer. Chapter 7 Onboard Security Setup...
  • Page 115 PCA-6178 User's Manual...

  • Page 116: Programming The Watchdog Timer

    Programming the Watchdog Timer The PCA-6178 is equipped with a watchdog timer that resets the CPU or generates an interrupt if processing comes to a standstill for any reason. This feature ensures system reliability in industrial standalone or unmanned environments.

  • Page 117: Appendix A Programming The Watchdog Timer

    The value range is from 01 (hex) to 3F (hex), and the related time interval is 1 sec. to 63 sec. Data Time Interval 1 sec. 2 sec. 3 sec. 4 sec. • • • • • • 63 sec. PCA-6178 User's Manual...

  • Page 118: Appendix A Programming The Watchdog Timer

    After data entry, your program must refresh the watchdog timer by rewriting I/O port 443 (hex) while simultaneously setting it. When you want to disable the watchdog timer, your program should read I/O port 443 (hex). The following example shows how you might program the watchdog timer in BASIC: Watchdog timer example program OUT &H443, data REM...
  • Page 119 PCA-6178 User's Manual...

  • Page 120: Appendix B Pin Assignments

    Pin Assignments This appendix contains information of a detailed or specialized nature. It includes: • IDE Hard Drive Connector • Floppy Drive Connector • Parallel Port Connector • SCSI Connector • USB Connector • VGA Connector • Ethernet 10/100Base-T RJ-45 Connector •...

  • Page 121: Ide Hard Drive Connector (Cn1, Cn2)

    DATA 0 DATA 15 SIGNAL GND DISK DMA REQUEST IO WRITE IO READ IO CHANNEL READY HDACKO* IRQ14 ADDR 1 ADDR 0 ADDR 2 HARD DISK SELECT 0* HARD DISK SELECT 1* IDE ACTIVE* * low active PCA-6178 User's Manual...

  • Page 122: Floppy Drive Connector (Cn3)

    B.2 Floppy Drive Connector (CN3) Table B-2: Floppy drive connector (CN3) Signal Signal FDHDIN* FDEDIN* INDEX* MOTOR 0* DRIVE SELECT 1* DRIVE SELECT 0* MOTOR 1* DIRECTION* STEP* WRITE DATA* WRITE GATE* TRACK 0* WRITE PROTECT* READ DATA* HEAD SELECT* DISK CHANGE* * low active Appendix B Pin Assignments...

  • Page 123: Parallel Port Connector (Cn4)

    B.3 Parallel Port Connector (CN4) Table B-3: Parallel port connector (CN4) Signal Signal STROBE* AUTOFD* INIT* SLCTINI* ACK* BUSY SLCT * low active PCA-6178 User's Manual...

  • Page 124: Scsi Connector (Cn5)

    B.4 SCSI Connector (CN5) 34 33 68 67 36 35 Table B-4: SCSI connector (CN5) Function Function SD+12 SD-12 SD+13 SD-13 SD+14 SD-14 SD+15 SD-15 SDP+1 SDP-1 SD+0 SD-0 SD+1 SD-1 SD+2 SD-2 SD+3 SD-3 SD+4 SD-4 SD+5 SD-5 SD+6 SD-6 SD+7 SD-7...

  • Page 125: Usb Connector (Cn6)

    B.5 USB Connector (CN6) Table B-5: USB1/USB2 connector (CN6) USB1 Signal USB2 Signal +5 V +5 V Chassis GND B.6 VGA Connector (CN7) Table B-6: VGA connector (CN7) Signal Signal GREEN BLUE H-SYNC V-SYNC PCA-6178 User's Manual...

  • Page 126: Ethernet 10/100Base-T Rj-45 Connector (Cn8)

    B.7 Ethernet 10/100Base-T RJ-45 Connector (CN8) Table B-7: Ethernet 10/100Base-T RJ-45 connector (CN8) Signal XMT+ XMT- RCV+ RCV- B.8 COM1/COM2 RS-232 Serial Port (CN9, CN10) Table B-8: COM1/COM2 RS-232 serial port (CN9, CN10) Signal Appendix B Pin Assignments...

  • Page 127: Keyboard And Mouse Connnector (Cn11)

    B.9 Keyboard and Mouse Connnector (CN11) Table B-9: Keyboard and mouse connector (CN11) Signal KB DATA MS DATA KB CLOCK MS CLOCK B.10 External Keyboard Connector (CN12) Table B-10: External keyboard connector (CN12) Signal DATA PCA-6178 User's Manual...

  • Page 128: Ir Connector (Cn13)

    B.11 IR Connector (CN13) Table B-11: IR connector (CN13) Signal Signal +5 V FIRRX CIRRX IR_RX +5VSB IR_TX B.12 CPU Fan Power Connector (CN14) Table B-12: CPU fan power connector (CN14) Signal +12 V Detect Appendix B Pin Assignments...

  • Page 129: Power Led And Keylock Connector (Cn16)

    B.14 External Speaker Connector (CN17) The CPU card has its own buzzer. You can also connect it to the external speaker on your computer chassis. Table B-14: External speaker (CN17) Function +5 V Internal buzzer Speaker out PCA-6178 User's Manual...

  • Page 130: Reset Connector (Cn18)

    B.15 Reset Connector (CN18) Table B-15: Reset connector (CN18) Signal RESETIN B.16 HDD LED Connector (CN19) Table B-16: HDD LED connector (CN19) Signal (LED+) LED0 (LED-) B.17 ATX Feature Connector (CN20) Table B-17: ATX feature connector (CN20) Signal PS-ON Appendix B Pin Assignments...

  • Page 131: System I/O Ports

    360-36F Reserved 378-37F Parallel printer port 1 (LPT2) 380-38F SDLC, bisynchronous 2 3A0-3AF Bisynchronous 1 3B0-3BF Monochrome display and printer adapter (LPT1) 3C0-3CF Reserved 3D0-3DF Color/graphics monitor adapter 3F0-3F7 Diskette controller 3F8-3FF Serial port 1 Watchdog timer PCA-6178 User's Manual...

  • Page 132: Dma Channel Assignments

    B.19 DMA Channel Assignments Table B-19: DMA channel assignments Channel Function Available Available Floppy disk (8-bit transfer) Available Cascade for DMA controller 1 Available Available Available B.20 Interrupt Assignments Table B-20: Interrupt assignments Priority Interrupt# Interrupt source Parity error detected IRQ0 Interval timer IRQ1...

  • Page 133: 1St Mb Memory Map

    INT A, B, C, D GNT D Note: In the PCA-6178VS/F, SCSI devices use "GNTA" signals via PCI slot 1. Therefore, PCI slot1 cannot be used for plug-in bus master add-on cards such as SCSI cards or LAN cards. PCA-6178 User's Manual...

  • Page 134: Appendix C Diskonchip® 2000 Installation Guide

    ® DiskOnChip 2000 Installation Guide This appendix contains information on ® the DiskOnChip 2000 quick installation guide. It includes: ® • DiskOnChip 2000 Installation Instructions • Additional Information and Assistance...

  • Page 135: Diskonchip 2000 Quick Installation Guide

    The DiskOnChip should be the only disk in the systems or would be configured as the first disk in the system (c:) using the DUPDATE utility. DUPDATE C /S: DOC104.EXB /FIRST (set as c:) DUPDATE D /S: DOC104.EXB (set as d:) PCA-6178 User's Manual...

  • Page 136: Addtional Information And Assistance

    C.1.2 Addtional information and assistance 1. Visit M-Systems' website at http://www.m-sys.com where you can find the Utilities Manual, data sheet and Application Notes. In addition, you can find the latest DiskOnChip 2000 software utilities. 2. Contact your dealer for technical support if you need additional assistance, and have the following information ready: •...
  • Page 137 PCA-6178 User's Manual...

This manual is also suitable for:
