Microtek ArtixScan DI 5240 Start Here Manual page 8

6. Click the Preview button to perform a preliminary view of the entire image. When done, a
preview image appears in the Preview window.
Do not forget to put the document back on the document feed tray.
7. Go to the "General" panel by clicking the General tab in the Settings window. Specify the
settings for your requirements there.
a) If necessary, specify the image settings for the front
or back side of documents separately by using the
Sides of Material control when Scan Source is set as
"ADF (Duplex)".
b) Select the image type in the Document Type as your
input image type.
– Select Photo to scan color prints.
– Select Text to scan text.
c) If necessary, check "Double Feed", then select a
suitable paper thickness for the ultrasonic double-feed
detection in the Paper Type options menu to prevent
multiple pages from being fed together while papers are
fed through the ADF.
d) If necessary, check "Remove Blank Page" and "Remove
Punch Hole" to enhance the quality of the scanned
images.
8. If necessary, go to the "Image Process" panel by clicking the Image Process tab in the Settings
window. Use the image correction tools presented there to enhance the image quality according
to your specific requirements.
9. Click the OK button to close the Scan Setup interface and return to the Main interface of
ScanWizard DI.
10. In the Main interface, click the File Format menu button to select a file format for the scanned
images.
11. In the Main interface, click the File Name menu button to specify a file naming method for the
scanned images.
12. In the Main interface, select and click the Normal Scan button to start scanning.
When done, the scanned images will be automatically saved into the folder defined in the File
Location menu box. At the same time, the scanned images will be displayed in thumbnail sizes
in the Thumbnail View window and labeled with the file name and file format specified earlier.
13. Click the Open Folder button to locate the scanned images if you want to view.
NOTE: For more details on other scanning scenarios applicable to your scanner, refer to the scanner
user's manual.
8
