If the writing has already been there for a long time, it may be necessary to wipe over the writing several times
and with slightly increased pressure! Therefore, it is recommended to wipe off the writing daily, or at least
once a week!
Caution: Aggressive cleaning agents, such as acetone, ethyl butyl acetate or disinfectants can
damage the whiteboard surface if left on for a long time! Please avoid such cleaning agents or
use them only for a short time, and then rinse the surface to remove any residues of these
cleaning agents!
4.

Rechargeable battery

When fully charged, the capacity of the battery is sufficient to move the desk (without load) approx. 50 times
throughout the complete height adjustment range.
An additional load on the desktop, or unfavourable external conditions (such as high temperature or additional
use of the USB charging socket at the front of the battery) will reduce this capacity.
Caution: To prevent deep discharge of the battery, please check the battery charge level at least
every 3 months and recharge, if necessary.
When the charge level is very low (below 10%), an acoustic warning signal will be given. If the charge level is
below 5%, the battery's power output is deactivated. Please charge the battery immediately so that it is not
damaged due to the low charge level.
4.1

Checking the battery charge level

To check the charge level, there is a button and 4 LEDs at the front of the battery. After pressing the button
(see Fig. 4.1 a), the LEDs (see Fig. 4.1 b) indicate the current charge level of the battery:
1 LED flashes
1 LED glow
2 LEDs glow
3 LEDs glow
4 LEDs glow
After a few seconds, the LEDs are switched off again to maintain the charge level.
During the use of the battery (adjusting the table or charging small devices) or a charging process, the charge
level is continuously displayed.
The battery charge is less than 10%. The power output is deactivated if the
charge is less than 5%.
Please charge the battery immediately so that it is not damaged due to the
low charge level.
The battery is charged up to 25%.
The battery is charged up to 25–50%.
The battery is charged up to 50–75%.
The battery is more than 75% charged.
Fig. 4.1 a
38
Fig. 4.1 b
