SmartHandle AX Advanced Scandinavian Oval
Area
S
S
S
S
S
S
S
S
M
M
M
M
M
M
M
M
L
L
L
L
L
L
L
L
27
Abbildungen/Images
Door thickness (mm)
32 – <36
32 – <36
36 – <41
36 – <41
41 – <46
41 – <46
46 – <51
51 – 54
52 – <56
52 – <56
56 – <61
56 – <61
61 – <66
61 – <66
66 – <71
71 – 74
72 – <76
72 – <76
76 – <81
76 – <81
81 – <86
81 – <86
86 – <91
91 – 94
Spindle length (mm)
84
94
84
94
84
94
94
94
104
114
104
114
104
114
114
114
124
134
124
134
124
134
134
134
5. Installing the fitting
Ring position
3
5
2
4
1
3
2
1
3
5
2
4
1
3
2
1
3
5
2
4
1
3
2
1
