Chapter-1

General lnformation

The CI770A/C is All-In-One board which could apply to the use of Networking,
POS or Automation Control Board. It is designed to combine all necessary input and output
affects interfaces, which makes it to be ideal All-In-One control board for the demand of
Networking, POS and Automation Control applications.
High-performance and power-efficient communication platform, the embedded motherboard
of CI770A/C is specially designed for advanced POS systems where the economical use of
power is in high demand. Also, the high performing CI770A/C comes with two
DDR3 1066/1333 MHz SO-DIMM slots with up to 16GB memory and four SATA ports.
This motherboard will ensure the high performance levels required for today's most popular
POS/Automation control applications including POS, ATM, and Panel PC applications.
CI770A/C has Intel LAN chipset with 10/100/1000 Mbps Ethernet for seamless broadband
connectivity. With the Wake-On LAN function and the PXE function in BIOS for Intel LAN
chipset, it is perfect control board for networking devices
CI770A/C also supports with multi-COM ports of five RS232 and one RS232/422/485 to meet
the needs of connectivity for multiple COM ports. In addition, there are multi-ports of Hi-Speed
USB 3.0/2.0 to enhance the host controller interface which will ensure the high performance
level and flexible expansion. The CFast Card socket (option) supports SATA interface 2.0. A
single Flash chip holds the system BIOS, and you can change the Flash BIOS by
the Utility Update.
The supported display interfaces include DVI-D, VGA, LVDS and HDMI. With a small footprint
of only 200 x 150 mm and advanced performance in both computing and graphics, this board
meets the requirement of system developers in the gaming, POS, digital signage, and server
market segment.
