PCI Express Root Port 3/4
Control the PCI Express Root Port.
The optional settings are: Enabled, Disabled.
PCIe Speed
Select PCI Express port speed.
The optional settings are: Auto, Gen1, Gen2.
4-8-1-1-2 ► PCI Express x 1
Main
Advanced
PCI Express Root Port 7/8
PCIe Speed
PCI Express Root Port 7/8
Control the PCI Express Root Port.
The optional settings are: Enabled, Disabled.
PCIe Speed
Select PCI Express port speed.
The optional settings are: Auto, Gen1, Gen2
Chipset
Boot
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Security
Save & Exit
[Enabled]
[Gen1]
75
Control the PCI
Express Root Port.
→←: Select Screen
↑ ↓ : Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Esc: Exit
