1-2 Specification
1. CPU: Intel Mobile Sandy Bridge processor in Socket G2 package (rPGA988B)
2. Chipset: Intel Panther Point Platform Controller Hub (PCH) QM77
3. Memory: 2 x DDR3 SO-DIMM socket (up to 16GB)
4. Graphics: Integrated with Intel Mobile Sandy Bridge Processor
5. SIO and UARTs: Fintek F71869A and F81216AD I/O chipset
6. NAND flash memory (Option): Support One CFast card socket type II for SATA interface
On board SATA SSD 2/4/8/16/32/64 GB (Option)
7. SATA: 4 x SATA ports (2 x SATA 2.0 and 2 x SATA 3.0)
8. LAN Interface: One Intel 82579LM GbE LAN PHY and one Intel 82574L GbE LAN
9. Storage Device: 1 x 24pin CFast card socket
10. Serial Port: 5 x RS232 or 485 + 1 x RS485 / 422 / 232
11. USB: 4 x external USB 3.0/2.0 & 5 x internal USB2.0
12. Sound: Intel HD Audio Specification 1.0 Two channel sound
13. LVDS: support 24bits/2ch LVDS interface
14. WDT / DIO: Hardware watch dog timer support, 0~255 sec programmable
Hardware digital Input & Output, 8 x DI / 8 x DO
15. Touch screen (optional): C8051F321 USB/COM interface touch screen controller,
support 4-, 5-, 8- wire Analog resistive touch screen
16. Audio Amplifier: ANPEC APA4863 Class AB 2.2W Audio amplifier
17. Expansion interface: 1 x PCI Gold finger & 1 x PCIe Mini card for PCIe by one and
USB interface & 1 x PCIe Mini card for PCIe by one OR mSATA and USB interface
18. BIOS: AMI UEFI BIOS
19. Dimension: 200 x 150 mm
20. Power: On board DC-IN Convert into system power +12VAD/±5% to +5V/±5%
and +3.3V/±5%
21. Two 3G SIM card socket
6
