4-7-9-1 Serial Port 3~6 Configuration

Main Advanced
Serial Port 3~6 Configuration
Serial Port
Device Settings
Change Settings
COM3 422/485 control flow
Serial Port
Use this item to enable or disable serial port (COM).
The optional settings are: Enabled, Disabled.
Change Settings
Use this item to select an optimal setting for super IO device.
The optional settings are:
AUTO
IO=260h; IRQ=11;
IO=260h; IRQ=10,11,12;
IO=268h; IRQ=10,11,12;
IO=270h; IRQ=10,11,12;
IO=278h; IRQ=10,11,12;
COM3 422/485 control flow
Use this item to enable or disable serial port (COM) Autoflow
The optional settings are: Enabled, Disabled.
Chipset Boot
[ Enabled ]
IO=260h; IRQ=11;
[ AUTO ]
[Disabled]
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Security Save & Exit
71
Enable or Disable Serial
Port (COM)
→←: Select Screen
↑ ↓ : Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Esc: Exit
