Enable WatchDog

void F75111_SetWDTEnable (BYTE byteTimer)

{

WriteByte(F75111_INTERNAL_ADDR,WDT_TIMER_RANGE ,byteTimer);

WriteByte(F75111_INTERNAL_ADDR,WDT_CONFIGURATION,WDT_TIMEOUT_FLAG | WDT_ENABLE | WDT_PULSE | WDT_PSWIDTH_100MS);

}

Disable WatchDog

void F75111_SetWDTDisable ()

{

WriteByte(F75111_INTERNAL_ADDR,WDT_CONFIGURATION,0x00);

}

// set WatchDog range and timer

// Enable WatchDog, Setting WatchDog configure

// Disable WatchDog
