SATA Controller Speed
Indicates the maximum speed the SATA controller can support.
The optional settings: Gen1, Gen2, Gen3.

Software Feature Mask Configuration

Please refer section 4-7-4-1-1
4-7-4-1-1 ►Software Feature Mask Configuration
Main
Advanced
RAID0
RAID1
RAID10
RAID5
RAID0,RAID1,RAID10,RAID5
Enable or disable RAID0, RAID1, RAID10, RAID5 feature.
The optional settings: Enabled, Disabled.
4-7-4-2 SATA Mode Selection - RAID Mode
Main
Advanced
SATA Controller(s)
SATA Mode Selection
SATA Controller Speed
►Software Feature Mask Configuration
Alternate ID
Chipset
Boot
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Chipset
Boot
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Security
Save & Exit
[Enabled]
[Enabled]
[Enabled]
[Enabled]
Security
Save & Exit
[Enabled]
[RAID]
[Gen3]
[Disabled]
66
Enable or disable
RAID0 feature.
→←: Select Screen
↑ ↓ : Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Esc: Exit
Enable or disable
SATA Device.
→←: Select Screen
↑ ↓ : Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
Esc: Exit
