19-PIN CONNECTOR ELECTRICAL CONNECTIONS

5.10 USER INTERFACE

9-pin male connector
Pin
2
3
5
7
8
How To Build A Simple Interface Test Cable:
The following wiring diagram shows a simple test cable including power, external (push-
button) trigger and PC RS232 COM port connections.
Matrix 400™
RS232 PC-side connections
1 5
6 9
Name
RX
TX
GND
RTS
CTS
M16 19-pin female
TX
O
S
RX
L GND
A
Vdc
B I1A
C
I1B
Trigger
Figure 99- Test Cable for Matrix 400™
1 13
14 25
25-pin male connector
Pin Name
3
2
7 GND
4 RTS
5 CTS
9-pin D-sub female
2
RX
3
TX
5
GND
Power Supply
Power GND
VS (10 – 30 VDC)
5
RX
TX
PC
81
