Reference Software Versions:
1.4.0 and later
History
Issue
Date
Rev. 0
February 13, 2015
Rev. A
March 24, 2015
Rev. B
June 9, 2015
Rev. C
April 2016
Rev. D
April, 2017
APPLICATION NOTE
XRF410N™
Installation
Paragraph
Change
First Release
Added baud rate note
Added Electrical connection diagrams and
power supply table.
Added CAB-MLP-05 wiring info
Changed power supply table.
Advertisement
Table of Contents
Related Manuals for Datalogic XRF410N Series
Summary of Contents for Datalogic XRF410N Series
- Page 1 APPLICATION NOTE XRF410N™ Installation Reference Software Versions: 1.4.0 and later History Issue Date Paragraph Change Rev. 0 February 13, 2015 First Release Rev. A March 24, 2015 Added baud rate note Rev. B June 9, 2015 Added Electrical connection diagrams and power supply table.
- Page 2 XRF410N™ INSTALLATION INTRODUCTION XRF410N (named for its eXtended Reading Field), is a product developed mainly for T&L applications with the goal of guaranteeing an extended horizontal field of view in order to fully cover the entire width of a conveyor. It is made up of two Matrix 410N™...
- Page 3 XRF410N™ INSTALLATION The following table summarizes the main characteristics of the various models: Model 1D Code Pitch Lighting Reading Focus Overlap Others XRF410N Resolution [mm] System Distance [mm] Dist. min. [mm] [mm] [mm] between readers [mm] 0.38mm Cropped BP- B0x 1270- (15mils) LT-10...
- Page 4 XRF410N™ INSTALLATION The complete list of XRF410N models is: Description Part Number XRF410N-B00 2HD_MED RES_MASTER 937400028 XRF410N-B10 2HD_HI RES_MASTER 937400029 XRF410N-H00 2HD_HI PERF_MED RES_MASTER 937400030 XRF410N-H10 2HD_HI PERF_HI RES_MASTER 937400031 XRF410N-H20 2HD_HI PERF_VHI RES_MASTER 937400032 XRF410N-B01 2HD_MED RES_EXTENSION 937400033 XRF410N-B11 2HD_HI RES_EXTENSION 937400034 XRF410N-H01 2HD_HI PERF_MED RES_EXTENS 937400035...
- Page 5 XRF410N™ INSTALLATION Required Accessories for XRF410N High Performance Models Description 1 Module 2 Modules 4 Modules Part Number XRF410N-H10 2HD_HI PERF_HI RES_MASTER 937400031 XRF410N-H11 2HD_HI PERF_HI RES_EXTENS 937400036 CAB-ETH-M05 M12-IP67 ETHERNET CABLE (5M) 93A051348 CBL-1480-05 M12/5P MALE/FEMALE 5M IDNET 93A050051 CBL-1480-02 M12/5P MALE/FEMALE 2M IDNET 93A050050 CAB-DS05-S M12-IP67 TO CBX 5M...
-
Page 6: Installation
XRF410N™ INSTALLATION INSTALLATION GENERAL ID-NET CONFIGURATION When using a single XRF410N-xx0 MASTER, no ID-NET network configuration is necessary. This product leaves the factory pre-configured and the readers have respective Master and Slave 1 roles. When using one or more XRF410N-xx1 EXTENSION(s) with the XRF410N-xx0 MASTER, the first step is to configure the ID-NET network because the EXTENSION Slave readers leave the factory with the unusable Slave 0 role (jolly). -
Page 7: Direct Mounting
XRF410N™ INSTALLATION DIRECT MOUNTING For Top direct applications mount the positioning bracket to the Bosch frame using the two T- bolts and nuts through the slots in the bracket. Figure 1 – Positioning Bracket Mounting to Frame Next, install the front mounting bolt so that the XRF410N rests on the positioning bracket. This allows positioning to be done without having to physically support the weight of the XRF410N. - Page 8 XRF410N™ INSTALLATION When using multiple Modules on the same plane (Master + Extension(s)), the distance between readers must be maintained from one module to the next to guarantee uniform image acquisition overlapping. Figure 3 – Maintaining Pitch Between Multiple Modules Example Mounting Distance for XRF410N B0x Models Minimum Reading...
- Page 9 XRF410N™ INSTALLATION MOUNTING WITH EMK MIRRORS Accessory EMK-600 External Deflection Mirrors (as well as some other models), can be mounted in all applications where it is not practical to use the full DOF of the reader. In these cases a more compact reading station can be constructed. This is particularly useful in side reading applications.
- Page 10 XRF410N™ INSTALLATION EMK-600 Side Mount - Standard XRF410N and EMK-600 Mirror alignment is maintained when the EMK is mounted directly to the frame profiles. The skew angle is made at the mirror instead of at the reader. 1. Mount the mirror brackets to the profiles with one bolt in the center position and one bolt in the outer ring.
- Page 11 XRF410N™ INSTALLATION EMK-600 Side Mount - Alternative An alternative mounting solution is to use the ST-344 Bracket. XRF410N and EMK-600 Mirror alignment is obtained when the EMK is centered to the frame profiles as shown in the figures below. This bracket also provides the freedom of applying offsets to the mirror where necessary.
-
Page 12: Electrical Connections
XRF410N™ INSTALLATION ELECTRICAL CONNECTIONS Single Master Base Model Applications ID-NET™ XRF410N Terminator Master Power CBL-1480-05 CBX500 ATS CAB-DS05-S P.S. Ethernet Host Figure 6 –Bxx Single Module Electrical Connections ID-NET™ Terminator on Slave to Ethernet Host CBL-1480-05 from Master ID-NET to Slaves from CBX CAB-DS05-S to Master from CBX... - Page 13 XRF410N™ INSTALLATION Multiple Base Model Applications (Master + Extensions) Ethernet Host XRF410N Extension CBL-1480-05 Power CBX500 ATS XRF410N XRF410N Master Extension P.S. ID-NET™ Terminator Figure 8 – Bxx Multiple Module Electrical Connections CBL-1480-05 ID-NET™ Terminator to Ethernet Host from Master on last Slave ID-NET to Slaves from CBX...
- Page 14 XRF410N™ INSTALLATION Single Master Hi Performance Model Applications ID-NET™ XRF410N Terminator Master CAB-MLP-05 Power CBL-1480-05 CBX500 ATS CAB-DS05-S P.S. Ethernet Host Figure 10 –Hxx Single Module Electrical Connections ID-NET™ Terminator CAB-MLP-05 on Slave Illuminator Power CBL-1480-05 to Ethernet Host ID-NET to Slaves from Master from CBX CAB-DS05-S...
- Page 15 XRF410N™ INSTALLATION 3 Module Hi Performance Model Applications (Master + Extensions) Ethernet Host XRF410N Extension CBX500 ATS CBL-1480-05 XRF410N XRF410N Master Extension P.S. ID-NET™ Terminator Figure 12 – Hxx Multiple Module Electrical Connections ID-NET™ Terminator on last Slave CAB-MLP-05 Illuminator Power CBL-1480-05 to Ethernet Host Protection cap...
- Page 16 XRF410N™ INSTALLATION 6 Module Hi Performance Model Applications (Master + Extensions) Ethernet Host PWR-480B XRF410N Extensions CBX500 ATS CBL-1480-05 CBL-1480-05 PWR-480B ID-NET™ Terminator XRF410N Extensions Figure 14 – Hxx 6 Module Electrical Connections ID-NET™ Terminator on last Slave CAB-MLP-05 Illuminator Power CBL-1480-05 to Ethernet Host Protection cap...
-
Page 17: Default Configuration
XRF410N™ INSTALLATION SOFTWARE CONFIGURATION THROUGH DL.CODE DEFAULT CONFIGURATION Each XRF410N model has its own default configuration (job) which is detailed in the tables and notes below. This job is loaded by default and should not be changed or deleted. Necessary modifications should be saved to a new job named for the application. NOTE: If the default job is ever accidentally deleted, backup files (.dlcfg) are provided in the DL.CODE mini-DVD (.zip file or accessory mini-DVD). - Page 18 XRF410N™ INSTALLATION In the Reading Phase step, set Acquisition Trigger Type to Periodic. The period to set depends on the application speed, the maximum code length, and the maximum pack height. To guarantee application functioning, two successive acquisitions must have an overlapping area in the direction of movement at least equal to the maximum code length.
- Page 19 XRF410N™ INSTALLATION PACKTRACK CONFIGURATION PackTrack applications have the same requirements and considerations as mentioned above for Phase Mode. They also require an Encoder to register line speed (conveyor). In addition the PackTrack calibration procedure must be executed in DL.CODE. See the DL.CODE User’s Manual in the DL.CODE Help menu.
