GENERAL VIEW

1 2
10
Device Class Label
1
Mounting Holes (12)
2
Lens Cover
3
Lens
4
(separate accessory)
Internal Illuminator
5
x
Matrix 400™
3
7
8
9
(separate accessory)
5
4
Figure A
HMI X-PRESS™ Interface
6
"POWER ON" LED
7
Power - Serial Interfaces - I/O Connector
8
Ethernet Connector
9
Ethernet Connection LED
10
(Ethernet Models Only)
2
2
6
(Ethernet Models Only)
