19-pin Connector Pinout for Matrix 400™
The table below gives the pinout of the 19-pin M16 male connector for connection to the
power supply and input/output signals. Use this pinout when the Matrix 400™ reader is
connected by means of the 19-pin connector:
Pin Name
A Vdc
L GND
K CHASSIS
B I1A
C I1B
D I2A
E I2B
H O1+
F O1-
G O2+
I O2-
S RX
O TX
R ID+
P ID-
Pin
M
INTERFACE
U
N
SELECTABLE)
T
* Do not leave floating, see par. 5.4.2 for connection details.
4
Figure 3 - 19-pin M16 Male Connector
19-pin M16 male connector pinout
Function
Power supply input voltage +
Power supply input voltage -
Cable shield internally connected by capacitor to the
chassis
External Trigger A (polarity insensitive)
External Trigger B (polarity insensitive)
Input 2 A (polarity insensitive)
Input 2 B (polarity insensitive)
Output 1 +
Output 1 -
Output 2 +
Output 2 -
Auxiliary RS232 RX
Auxiliary RS232 TX
ID-NET™ network +
ID-NET™ network -
Name RS232
TX
MAIN
RX
(SW
RTS
CTS
MATRIX 400™ REFERENCE MANUAL
RS485
Full-Duplex
TX+
*RX+
TX-
*RX-
RS485
Half-Duplex
RTX+
RTX-
