MRL Series
Left Panel
(Fan Compartment)
WARNING
Avoid Serious Injury, Death, or Property Damage.
Maintain Clearances to Combustible to Prevent the Risk of Fire.
Clearances to combustibles must be maintained at
all times in order to prevent the ignition of
combustible materials. In locations used for the
storage of combustible materials, signs must be
posted to specify the maximum permissible stacking height to
maintain the required clearances from the heater to the
combustibles. Signs must either be posted adjacent to the
heater's thermostats or, in the absence of such thermostats, in a
conspicuous location. Clearances are provided on the heater's
safety label and in the heater's Installation, Operation, and
Maintenance manual. Product installation and operation must
comply with applicable standards, codes, and regulations. Post
this tag adjacent to the heater's thermostat or controls before
operating the heater.
- INSTALLER: READ AND POST THIS NOTICE -
F/N: LL001 - Clearance Safety Tag
(Affix adjacent to heater's thermostat)
Right Panel
(Valve Compartment)
LED CODE
Initial flash on power up,
then steady off
Steady on
1 flash
2 flashes
4 flashes
No flash on 117V start-up
NOTE: Lockout LED CODE appears on completion of the soft lockout operation.
F/N: LLTB007(3)
(Affixed under the lid)
California Proposition 65
!
This product can
expose you to
chemicals including
lead and carbon
monoxide, which are known to the
State of California to cause birth
defects or other reproductive harm.
For more information go to
www.P65Warnings.ca.gov.
LL001-XM-07/18 (CDS)
16" Burner Tube
5
1.0 Introduction • Safety Labels and Their Locations
FAULT STATUS FAULT CODE DELAY
No fault, normal operation No delay
Module failure / Internal fault No delay
Ignition failure 3 minutes
APS air flow fault
1-30 seconds
NOTE: fan/intake/exhaust
Erroneous flame signal No delay
Transformer fault No delay
F/N: LLV2EP9
F/N: LLV2EP15
SERVICE ACCESS PANEL
IGNITER & FLAME SENSE COMPARTMENT
1. Turn off gas & electricity.
2. Remove cover by lifting top
cover upward and outward.
CAUTION: HOT SURFACE.
KEEP COVER IN PLACE. REMOVE FOR SERVICE ONLY.
F/N: LLTB026
HIGH
24V
LOW
24V OUT
- 24V HEATER OUTPUT -
F/N: LLV3EP4
White Crescent
