MicroTech III Unit Controller LED Faults (Continued)
Freeze Fault Detect
Description
Freeze Fault Detect
• Low entering water temperature (below 35°F standard range or 13.5°F extended range)
Condensate Overflow (Freeze Fault Protection Only)
Description
Condensate Overflow
• Poor condensate drain.
• Check the resistance to ground on condensate wire. This should be open if there is no water in the pan.
Serial EEPROM Corrupted
Description
Serial EEPROM Corrupted
• Disconnect the BAS communication wiring and cycle power to the controller
○ If the alarm clears confirm that the BAS is not writing setpoints values that are out of range
○ If the alarm persists replace the controller
Waterside Economizer Low Temp Cutout (WSE Control & Call for Cooling)
Description
Waterside Economizer Low Temp
Cutout (WSE Control & Call for
Cooling)
• Water temperature is below 35°F.
Service Test Mode Enabled
Description
Service Test Mode Enabled
• Jumper JP1 is shorted for test mode operation.
Unoccupied Mode
Description
Unoccupied Mode
• Terminal U on main control board is connected to common from external source or commanded by network.
Occupied, Bypass, Standby, Modes
Description
Occupied, Bypass, Standby, Override
Modes
• Unit is operating normal. It may currently have a control signal or ready to operate when a control signal is active.
Baseboard Communication Fail
Description
Baseboard Communication Fail
• Verify jumper JP8 on main board is shorted.
• Verify connection of cable between H5 on main board and H1 on I/O expansion board.
Entering Water Temp Sensor Fail (Boilerless Electric Heat, Hydronic Heat or Waterside Economizer
Only)
Description
Entering Water Temp Sensor Fail
(Boilerless Electric Heat or Waterside
Economizer Only)
• Verify jumper JP8 on main board is shorted.
• Verify connection of cable between H5 on main board and H1 on I/O expansion board.
Low Entering Water Temperature (Heating) (No Display On Boilerless Electric Heat)
Description
Low Entering Water Temperature (No
Display On Boilerless Electric Heat)
• Verify entering water temperature is greater than set point.
