Service Manual
MX22036 & MX19042 Pump &
Models: MX22036‡‡-XXX & MX19042‡‡-XXX, ‡‡ = PP (PTFE), PU (PTFE/UHMW), PL (PTFE/LEATHER), UL
Patent 7,603,855.
Air consumption @ 20 cycles/min and 7 bar [101.5 psi] air
Maximum recommended continuous cycle rate (cycles/min):
A
C
B
77-3210-R1.4
Packages
(UHMW/LEATHER), UU (UHMW/UHMW)
SPECIFICATION - Bare Pump
Maximum air inlet pressure:
Maximum fluid pressure:
Displacement per cycle:
Output @ 60 cycles/min:
Air inlet connection:
Fluid inlet connection:
Fluid outlet connection:
Sound level @ 7 Bar:
Wetted parts materials of construction:
MX22036
Ratio:
8 bar [116 psi]
288 bar [4176 psi]
220 ml [7.4 oz]
13.2 l/m [3.5 US
gal/m]
inlet pressure:
Weight:
1/36
MX19042
36:1
7 bar [101.5 psi]
294 bar [4263 psi]
190 ml [6.4 oz]
11.4 l/m [3.0 US
gal/m]
1132 l/m [40 SCFM]
20
3/4" BSPP (f)
1 1/4" NPT (f)
3/4" NPT (f)
81 Dba Leq
38 kg [84 lbs]
See fluid section
EN
42:1
