Summary of Contents for Binks Maple 15
- Page 1 Instruction Manual Maple 15 - Pump Model 104009...
- Page 2 Instruction Manual Page 2 of 28 Issue: 2.2...
- Page 3 Instruction Manual Index Section General Description Operating Principle Specifications Dimensions and Mounting Details Important Safety Information Installation - General Parts Lists Main Pump Parts Lists Air Motor Parts Lists Fluid Section Parts Lists Reference Maintenance – Air Motor Assembly Procedure Maintenance –...
- Page 4 The air valve design (patent pending) ensures a positive magnetic detent for the main and pilot air valves thus removing the possibility for a stall condition. The air motor also utilises the Binks Low Ice quick exhaust technology to prevent air valve freezing conditions when high cycle speeds are employed.
- Page 5 Instruction Manual Operating Principle – Section 1.2 The Assembly comprises of:- • Central Air Piston and ‘change over’ Valves • 2 off Quick Exhaust and muffler assembly • 2 off Dynamic Chambers and Fluid Pistons • 2 off Fluid Pressure Chambers each complete with Suction and Pressure Ball Check Valve Assemblies •...
- Page 6 Instruction Manual Specification – Section 1.3 Specification 50 mm Pump Nominal Stroke 1.97 ins Pump Ratio 0..375 Litres Nominal Flow Volume / Cycle 0.10 US Gall Fluid Output @ 60 cycles/min 22.5 Litres / min 6.0 US Gall / min Maximum Recommended Continuous Cycle Rate 20 Cycles /min Maximum Recommended Intermittent Cycle Rate...
- Page 7 Instruction Manual Dimensions and Mounting Details – Section 1.4 For Piped Exhaust Air, remove mufflers and add 192803 Plug and Adapter 192779 for 1” NB Hose Page 7 of 28 Issue: 2.2...
- Page 8 Therefore, it is recommended to read these instructions carefully before start-up. Binks cannot be held responsible for damage or malfunctions resulting from the non-observance of the operating instructions. These instructions including regulations and technical drawings may not be copied, distributed, used for commercial purposes or given to others either in full or in part without the consent of Binks.
- Page 9 Instruction Manual Important Safety Information - Section 2.1 Fire, Explosion and Electric Shock Hazard Improper grounding, poor ventilation, open flames or sparks can cause a hazardous condition and result in a fire, explosion, or electric shock. When installed and operated in accordance with its instructions, the pump is approved for operation in Zone 1 (Europe) & Division 1 (North America), hazardous locations.
-
Page 10: Installation - Section
Instruction Manual Installation – Section 3.1 Mount the pump securely and position the pump at a convenient height (below the lid height of the paint container), to allow for maintenance, visual observation, and periodic inspection. The wall mount bracket is included with all pumps. Exhaust silencer kits are available for these pumps if the air exhaust is required to be piped away from the pump rather than exhausting locally through the mufflers.
