Binks MX432 Quick Start Manual

MX432 32:1 Pump Systems for Air
Assist & Airless Finishing
SPECIFICATIONS
Ratio:
Maximum air inlet pressure:
Maximum fluid pressure:
Displacement per cycle:
Output @ 60 cycles/min:
Air consumption @ 20 cycles/min:
Maximum recommended
continuous cycle rate:
Air inlet connection:
Air piston diameter:
Stroke length:
Fluid inlet connection:
Fluid outlet connection:
Wetted parts materials of
construction:
Sound level:
We reserve the right to change the specifications without prior notice
ITW INDUSTRIAL FINISHING UK 2010
Patent Pending
32:1
8 bar [116 psi]
256 bar [3712 psi]
24 cc [0.8 oz]
1.4 L/m [0.4 gal/m]
147 LPM [5.2 SCFM] @20 LPM
20 cycles/min
3/8" BSP (m) and 1/4" NPS (m)
85 mm [3.3 in]
75 mm [3.0 in]
1/2" NPS (m)
3/8" BSP (m) / 3/8" NPS (m)
Stainless Steel, Tungsten Carbide,
Hard Chrome, PTFE, Polyethylene,
Leather
96.2 dB
EN
77-2946
page 1
