1-2. Flow chart to operation for IZS51-□□L (IO-Link type)
Start
Installation of ionizer
Refer to [2-1. Installation ].
Wiring of ionizer
Refer for [2-2. Electrical connection ].
Yes
Piping of ionizer
Air purge
Refer to [2-1. Installation ].
No
Pressure setting
Refer to [2-1-3. Adjustment of
Pressure (Flow adjustment) ]
Turn ON power supply
Set up IO-Link
Refer to [4-2. IO-Link master configuration ].
Ion generation frequency setting
Refer to [4-3. Communication date ].
Adjustment of offset voltage
Refer to [4-3. Communication date ].
Completed
