4. Installation

• Ensure the mains supply is switched off
• Remove the terminal cover by undoing
• Mark the position of the top wall mounting
• Fix the top mounting screw and leave
• Place the key hole in the top of the product,
• Mark the position of the lower mounting
4
• Remove the product and drill out the lower
• The 230V 50Hz supply and load cables can
and the circuit supply fuses are removed
or the circuit breaker turned off.
the fixing screw on the bottom of the
time switch.
screw. Drill out the top mounting hole taking
care to avoid any joists, electrical cables
or water/gas pipes that may be hidden
beneath the surface. Insert the rawl plug
into the hole.
2.5mm proud off of the wall.
over the screw head, and slide down.
hole on the wall using the wall plate
as a template.
mounting hole again taking care to avoid
any joists, electrical cables or water/gas pipes
that may be hidden beneath the surface.
Insert the rawl plug into the hole.
enter through the rear knock outs or the front
cable entry ports provided. If the rear knock
outs are being used, remove the blanking
plates and pass the supply and load cables
through the holes.
