5. Connection Diagram

• The terminals are marked as follows
230V Mains Voltage Switching
Mains Supply
6
230V 50Hz Mains Supply
Live (Brown or Red) to
Neutral (Blue or Black) to
Earth (Green/Yellow) to
Load
Switch Live (Brown or Red) to either;
Normally Open to mains voltage
appliance e.g. Immersion Heater
Normally CLOSED to mains voltage
appliance e.g. Fan
Leave the 'Link' or 'Bridge'
wire between
Neutral (Blue or Black) to
Earth (Green/Yellow) to
on the bottom of the wall plate;
Mains Supply
230V 50Hz
For a product brochure please contact:
230V 50Hz
Link or 'bridge wir e'
E N L
Link or 'bridge wir e'
E N L
1 2 3
L
N
2
3
L & 1
N
1 2 3
Load
