Installation - Timeguard NTM02 Installation & Operating Instructions Manual

• Power Status
• Output LED
• 7 Day Time Period: (7 Day, 5 + 2 Days
• Operating
• CE Approved
Power LED
2
Advance
button
Programme
button

4. Installation

• Ensure the mains supply is switched off
• Connect the installation wiring to the
LED Indicator:
Indicator:
Temperature:
Note: Not suitable for use with
Discharge Lighting.
and the circuit supply fuses are removed
or the circuit breaker turned off.
module, according to the legend printed on
the rear side of the time switch, or according
to the connection section below.
Red
Green
or Individual Day) –
4 ON/OFF switching
programmes per day
0°C to +40°C
Output LED
Reset
button
Illuminated Illuminat
screen screen
Boost
button
Time
button
