Timeguard NTT05 Installation & Operating Instructions Manual page 4

24 hour general purpose mechanical time switch

Power LED

Terminal

cover

Time control segments:

1 segment = 15 minutes,

push segment down

for ON, pull up for OFF.

segment

Control switch:

1 = permanently ON,

Timer symbol =

timed

control,

0 = permanently OFF.

Programme

ring

Time

indicator

Output LED
