• Place the key hole in the top of the
• Secure the unit to the wall using the lower
• If the wiring is through the front cable entry
• Terminate the supply and load cables to
• Secure the terminal cover back into place
5
product again, over the screw head,
and slide down.
mounting screw.
ports, use the cable clamps provided to
secure the supply and load cables.
the terminal block ensuring correct polarity
is observed and that all bare conductors
are sleeved. Please note the connections are
marked beneath the terminal block
(see section 5. Connection Diagram)
using the fixing screw.
