- Page 1 CX504 26” DRUM SANDER USER MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS General Safety Instructions ................3 Specific Safety Instructions................4 Features ....................... 5 Physical Features ..................6 Unpacking ....................7 Setup ......................7 Proper Grounding ..................7 Crank Handle....................8 Control Panel....................8 Pressure Rollers ................... 8 Pressure Rollers ................... 8 Sand Paper Replacement ................ -
Page 3: General Safety Instructions
GENERAL SAFETY INSTRUCTIONS Extreme caution should be used when operating all power tools. Know your power tool, be familiar with its operation, read through the owner’s manual and practice safe usage procedures at all times. ALWAYS read and understand the router bits, shaper heads, blades, user manual before operating the knives or making other adjustments or... -
Page 4: Specific Safety Instructions
CX504 sander, before operating it. DO NOT force the sander. It will do the If you fail to do so, serious injury could job better and will be safer at the occur. -
Page 5: Features
As part of the growing line of Craftex CX-Series woodworking equipment, we are proud to offer CX504 a 26” Drum Sander. By following the instructions and procedures laid out in this user manual, you will receive years of excellent service and satisfaction. The CX504 is a professional tool and like all power tools, proper care and safety procedures should be adhered to. -
Page 6: Physical Features
CX504 –DRUM SANDER PHYSICAL FEATURES Sanding Head Cover Conveyor Variable Feed 4" Dust Belt Control Knob Collection Ports Table Height ON/OFF Crank Handle Switch ON/OFF Switch Conveyor Belt Depth Gauge Conveyor Belt Tracking Adjustment Screw & Nuts Table Craftex CX-Series... -
Page 7: Unpacking
CX504. Always try to position your machine close to the CX504 is for use on a normal 220 volt power source so that you do not need to circuit. Make sure that the machine is use extension cords. -
Page 8: Crank Handle
To adjust the pressure rollers: Make sure the cord is disconnected form CONTROL PANEL the power source. The CX504 control panel is installed on the Remove the sanding head cover. Use a right side of the machine. Attach the control Philips... -
Page 9: Sand Paper Replacement
CONVEYOR BELT REPLACEMENT Conveyor belt tension and tracking are controlled by the adjustment screws located The CX504 is designed for 6" wide sand on the conveyor rollers, on front of the paper rolls. When installing sanding paper, machine shown in figure-7. -
Page 10: Basic Controls
TEST RUN This section tells you about the control Once you have assembled your milling panel on your CX504. The control panel is machine completely and performed the installed on the front side of the machine to necessary adjustments, it is then time for a the right. -
Page 11: Connecting To A Dust Collector
ADJUSTMENT tightly. It is recommended to use a proper sized dust collector with the CX504 to The CX504 features a table height crank ensure adequate dust collection. handle which allows you to raise or lower the table to desired height. -
Page 12: Maintenance
MAINTENANCE CLEANING During the life of your machine, you will The moisture from the wood dust remaining need to practice some regular maintenance on the conveyor belt and other parts of the to keep your sander in peak performance machine. The table and other unpainted condition. -
Page 21: Warranty
This warranty shall not apply to consumable products such as blades, bits, belts, cutters, chisels, punches etceteras. Craftex shall in no event be liable for injuries, accidental or otherwise, death to persons or damage to property or for incidental contingent, special or consequential damages arising from the use of our products.
