SF 28PT • Setup Guide (Continued)
7. To set the tap selector switch, use the provided grille hook to first remove the
speaker grille. Insert the small end of the hook through any perforation along
the outer edge of the grille and pull the grille off the speaker.
8.
Use an Extron Tweeker or small screwdriver to set the tap selector switch to
the desired position.
9.
Replace the grille.
NOTES:
• Wiring is the same for all hanging methods where PCC-2 cable is used. If it is not used, the 2-pole splicing
connectors at the speaker should be replaced with the provided 3-pole splicing connectors (see the
Installation and Configuration
• Setting the tap switch is the same for all installation methods.
• Follow steps 1 and 2 of
mounting methods.
• Be sure to allow extra cable length for the structure attachment points.

Optional Ceiling Bracket Kit

The optional SMK C SF 26PT Extron Ceiling Bracket Kit for 6-inch and larger
pendant speakers allows the SF 28PT speaker assembly to be suspended from
a octagon junction box. The kit consists of two ceiling brackets and matching
magnetic covers.
1. Install and wire an octagonal junction box where the ceiling bracket is to be
attached.
NOTE: The junction box must be attached to a permanent structural
member of the building and be able to support the complete
speaker assembly including the speaker and cap, cable, and the
ceiling bracket and cover plate (see the
2. Route the free end of the PCC-2 cable through the ceiling bracket cover (
with the magnetic side of the cover facing the ceiling bracket.
3. Keeping in mind how much speaker wire and steel cable will be required,
remove as much of the PCC-2 cable jacket as necessary such that the end
of the jacket remains flush with the top of the black center grommet (
the ceiling bracket.
4
on page 3).
Installing the Mounting Hardware
WARNING on page 1).
on page 2 before continuing with any of the optional
Ceiling Bracket
4 4 4
3 3 3
Cover Plate
)
1
PendantConnect-2
Cable
) of
2
Enclosure
Cloth Scrim Backing
Speaker Grille
Grille Hook
16W OFF
8
32W 64W
64W
32W
16W
8Ω
OFF 8W
Adjust the Tap Selector
Speaker
Steel Cables
3-Pole Splicing
Connector
Speaker Wires
2 2 2
Cable Lock
Min. 1"
4 4 4
3 3 3
2 2 2
Grommet
1 1 1
Cable Lock
Side View
Release
