7.1

Technical Data

7.1.1 Physical Features

All specified data was measured with nominal input voltage, at full load, and an
ambient temperature of 25 °C. The limit value tolerances are subject to the usual
variations.
Physical Feature
Operating voltage
Max. power of power supply
Power consumption
Level digital input
Current consumption digital input at
LOW potential
Sampling rate input
Digital output (open collector), max.
load
Max. voltage drop of the output in ON
condition
Max. transmission power cellular engine
MIRO-L100:
EGSM 900
GSM 1800
UMTS 900/2100
LTE 800/850/900/1800/2100/2600
MIRO-L110:
UMTS 850/1900/2100
LTE 700/1700/1900
Weight
Dimensions (width x height x depth)
Depth on DIN rail
Horizontal pitch on DIN rail
Temperature range
Maximum permissible humidity
IP rating(MIRO only)
Value
12 ... 24 V DC (±20 %),
reverse-polarity protected
< 4 kW
Typ. 1,5 W (MIRO/MIROdul-L1x0)
Typ. 1,8 W (MIRO/MIROdul-L2x0)
Max. 5 W
Level HIGH = 2 ... 24 V
Level LOW = 0 ... 1 V
Contact open condition: HIGH
Typ. 3 mA when connecting to GND
1 s
24 V (DC), 50 mA
< 1 V (DC) at 50 mA load
+33 dBm
+30 dBm
+24 dBm
+23 dBm
+24 dBm
+23 dBm
94 g (MIRO-L1x0)
100 g (MIRO-L2x0)
42 g (MIROdul-L1x0)
48 g (MIROdul-L2x0)
26 x 77 x 99 mm (MIRO)
82 x 70 x 17 mm (MIROdul)
92 mm (MIRO)
1.5 TE (MIRO)
-40 ... 70 ° C (extended 75 °C)
see  below
95 % non-condensing
Housing IP40
