MIRO
7.4

Connecting the connectors

The wires are contacted maintenance-free in the connector via a spring clip. Rigid
wires (stripped) or stranded wires with end sleeves are only inserted into the con-
nectors to clamp them. Stranded wires (braids) without end sleeve are clamped by
pushing in the white opener (e.g. using a flat-blade screw-driver with max. 2.5 mm
width). Unclamping a wire is also done by pushing in the opener.
The permissible wire cross-sections can be found in the following tables.
Wire
Nominal cross-section
Rigid
Flexible
Flexible with end sleeve
Table 8: Permissible wire cross-sections for connectors
7.5

Maximum line lengths

The maximum line lengths to the connections can be found in the following table.
Lines connected to the power supply or inputs and outputs must not go beyond
the building installation.
Wire
Antennas, power supply, inputs and outputs, other signals
Table 9: Permissible line lengths
Scope of Delivery
Cross-section
1.5 mm²
0.2 ... 1.5 mm²
0.2 ... 1.5 mm²
0.25 ... 1.5 mm²
Max. length
30 m
