ADA INSTRUMENTS AngleMeter 45 Operating Manual page 7

7
English
press the MITRE button (8) for ~2 sec. The displayed angle and the CNR
indicator (14) will flash once and the corner (CNR) angle is now stored in
memory.
If the stored corner angle does not need to be changed, press MITRE but-
ton (8) for ~1 sec to move to the next step.
Step 4: If you do not already have the MTR indicator (13) shown in the
display, press the MITRE button (8) for ~1 sec. This is the calculated mitre
angle for setting the saw. See angle M.
Step 5: Press the MITRE button (8) for ~1 sec to change the display to the
bevel angle. The BVL indicator (12) will be displayed. This is the bevel angle
for setting the saw. See Angle B.
Press the MITRE button (8) for ~1 sec to cycle back through the stored
spring angle, the stored corner angle and the calculated mitre and bevel
angles.
Press the ON/OFF button (7) at any time for ~1 sec to exit compound angle
mode.
Specifications
Power .........................................................3VDC 2xAAA Batteries (included)
Measuring range ......................................0-225°
Digital angle accuracy ............................. ±0.1°
Operating temperature ..........................-10°C to 50°C
Storage temperature................................-20° to 70°C
Battery life ................................................~100 Hrs
Shock resistance .....................................up to 1 m drop on concrete
