KVM- 1601 USER MANUAL
KVM- 1601
User Manual
Model: KVM- 1601

Advertisement

loading
Need help?

Need help?

Do you have a question about the KVM-1601 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for FS KVM-1601

  • Page 1 KVM- 1601 USER MANUAL KVM- 1601 User Manual Model: KVM- 1601...
  • Page 2: Table Of Contents

    5 . Cascade installation (optional) ............................3 3. Opening the Console .................................4 4. LED Instructions .................................. 4 5. OSD Operation ..................................5 6. OSD Functions ..................................6 7. OSD Hotkey Operation ..............................6 8. Specification ..................................7 9. FAQ ......................................8 www. fs.. com...
  • Page 3: Descriptions

    2) P lug the other blue port in the blue “Console” DB 15 port on the KVM. 3 ) Repeat above steps according to above diagram, it can maximum cascade up to 32 KVM switches. individual businesses. Its main characteristics: www.fs.com...
  • Page 4: Opening The Console

    Selection 2) A selected LED light (green) indicates that the computer attached to its corresponding port is Buttons & LEDs up and running. Station ID shows the current stage level of the daisy chain. Station ID www.fs.com...
  • Page 5: Osd Operation

    2. Click the right or middle button to confirm your selected port and close the OSD main menu at the same time. 3. Click the right button to exit the OSD main menu. *Note: Operate via keyboard after invoke the OSD menu via the touchpad. www.fs.com...
  • Page 6: Osd Functions

    1.Press【F3】and move the highlight bar with【↓】to select “OSD Hotkey” submenu . Press【Enter】and below screen appears: KVM default hotkey:【Scroll Lock】 2.KVM default hotkey:【Scroll Lock】 3.Select the“【Ctrl】【Ctrl】+【KVM Hotkey】 “ and pres s【Enter】, and then the 【Ctrl】hotkey is available in this hotkey mode, the mouse hotkey can't enter the OSD menu. www.fs.com...
  • Page 7: Specification

    KVM-1601 USER MANUAL Invoke hotkey: double click 【L_Ctrl】+ the corresponding function key Skip ports from 1 ~ 8 E. g. : Double click【 L_Ctrl】plus 2 to skip to the second port of the current + 1~8 station. Switching port Skip ports from9- 16 + F1~ F8 + t/↓...
  • Page 8: Faq

    KVM-1601 USER MANUAL 9. FAQ The KVM console doesn’t work when I connect and use the console for the first time. Solutions: 1) Power off the KVM and disconnect the monitor, keyboard and mouse. 2) Disconnect all the signal cables connected to the KVM.
  • Page 9 KVM-1601 USER MANUAL Solutions: 1)Invoke the OSD main menu and check the user name on the top left, make sure the user has got the access permission from the administrator. 2) Please contact the distributor or the KVM manufacturer. www.fs.com...
