Summary of Contents for FS KVM-0801
- Page 1 KVM-0801 User Manual KVM-0801 User Manual - 1 -...
-
Page 2: Table Of Contents
KVM-0801 User Manual Content 1.Descriptions............................3 2.Installation Instruction........................3 3.Opening the Console..........................4 4.LED Instructions........................... 4 5.OSD Operation............................. 5 6.OSD Functions............................6 7.Specifications............................8 8.FAQ................................. 9 - 2 -... -
Page 3: Descriptions
KVM-0801 User Manual 1.Descriptions KVM switch is a control device which controls multiple computers from a single console (keyboard, video and mouse), as many as 512 computers can be controlled from the original console. There is no better way to save space, time and money than with a KVM switch installation. -
Page 4: Opening The Console
KVM-0801 User Manual 3.Opening the Console The KVM makes two “beep” sounds and the LED flashes two times after power on. Then below window appears for you to input user name and password. The default password is “blank”, double click to 【Enter】 the OSD main menu to operate the KVM. -
Page 5: Osd Operation
KVM-0801 User Manual 4.OSD Operation Double click the right button of the mouse or double click hotkey 【 Scroll Lock】 to invoke below OSD main menu. You can customize the OSD hotkeys; find more details in OSD function instructions. To access the OSD menu through keyboard: 1.In the submenus that appear, moving the highlight bar to your selected port and then press... -
Page 6: Osd Functions
KVM-0801 User Manual 5.OSD Functions Menu Keys Submenu/explanation Set User Login-Set User login account and password Set accessible-Set access permissions BRC Mode -monitor multiple computers at the same time Load Default-reset the menu to the original factory default settings All-Lists all the ports on the installation... - Page 7 KVM-0801 User Manual 6.OSD Hotkey Operation Press【F3】and move the highlight bar with【↓】 to select “OSD Hotkey” submenu . Press 【Enter】and below screen appears: KVM default hotkey:【Scroll Lock】 Select the“【Ctrl】 【Ctrl】 +【KVM Hotkey】 “ and pres s【Enter】, and then the 【Ctrl】hotkey is availablein this hotkey mode, themouse hotkey can't enter the OSD menu.
-
Page 8: Specifications
KVM-0801 User Manual 7.Specifications Model 4 Port 8 Port 16 Port Computer Connections Port Selection Select buttons / OSD menu monitor 1x HDB-15 Female(blue) Console keyboard 2x USB type A mouse KVM port Connector (HDB-15 Female(yellow) Cascade port 1x HDB-15 Female(yellow) -
Page 9: Faq
KVM-0801 User Manual 8.FAQ 1. The KVM console doesn’t work when I connect and use the console for the first time. Solutions: 1) Power off the KVM and disconnect the monitor, keyboard and mouse. 2) Disconnect all the signal cables connected to the KVM.
