uick Reference Installation Guide
Q
Zip HydroTap G5
Command Centre -
BC HOME, BC H HOME, BC20, BC20 H, BC30, BC30 H,
BC40, BC40 H, BC60, BC60 H, BC100, BC100 H
Follow these steps for a safe and effective install.
1
Read the safety information
overleaf.
This QRIG may be sufficient
for installers who have
had previous HydroTap
installation experience.
Inexperienced installers
please scan the QR codes
for detailed installation
instructions.
2
Contact us if you need support and advice.
Zip Water Australia
67 - 77 Allingham Street, Condell Park NSW 2200
Postal: Locked Bag 80, Bankstown 1885
Australia, Tel (+612) 9796 3100, Free call 1800 947 827 (1800 ZIP TAP)
Zip Water UK
Trafalgar House, Rash's Green, Dereham,
Norfolk, NR19 1JG
United Kingdom, Tel 0345 6 005 005
Quick Reference Installation Guide
810006 v1.00 08.24 G5 BC Quick Reference Installation Guide
!
!
!
Installation
Full installation
videos
instructions
BC Home, BC H Home
BC20, BC20 H
BC30 , BC30 H
!
!
V
U
Full installation
instructions
BC40, BC40 H
BC60, BC60 H
BC100, BC100 H
!
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Zip HydroTap G5
Summary of Contents for Zip HydroTap G5
- Page 1 Zip Water Australia 67 - 77 Allingham Street, Condell Park NSW 2200 Postal: Locked Bag 80, Bankstown 1885 Australia, Tel (+612) 9796 3100, Free call 1800 947 827 (1800 ZIP TAP) Zip Water UK Trafalgar House, Rash’s Green, Dereham, Norfolk, NR19 1JG...
-
Page 2: Safety Information
• Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance. • The HydroTap G5 Home series is intended to be used in household and similar applications such as: • Staff kitchen areas in shops, offices and other working environments;... - Page 3 • The power cord and general power outlet must be in a safe and accessible position after installation. When positioning the appliance, ensure the power supply cord is not trapped or damaged. If the power supply cord is damaged it must be replaced by a Zip service provider or a qualified electrician.
- Page 4 Installation -Technical data, part supplied Review the technical data & parts supplied in the kit. Power rating, kW Dimensions Water supply Weight Model 220-240V, 50Hz W x D x H (mm) Connection (kg) BC100,BC100 H 2.1 + Booster 395 x 487 x 333 G 1/2 BC60,BC60 H 395 x 487 x 333...
- Page 5 Ventilation installation instructions Make sure there’s enough ventilation in the cupboard, air needs to circulate as follows: Cold air is drawn in through the gaps provided by the door buffers (supplied), they must be fitted. Command Centre clearances must be observed. Warm air is expelled through the integrated vent in the base of the Command Centre, via the vent cut-out in the cupboard floor.
- Page 6 Ventilation installation instructions BC Home, BC H Home, BC20, BC20 H, BC30, BC30 H ventilation options Option 1: Ventilation arrangement using small cupboard with min. 40mm overhang Directing warm air straight into the room. Must be installed C l e a r a Inlet Must be...
- Page 7 Ventilation installation instructions BC40, BC40 H, BC60, BC60 H, BC100, BC100 H ventilation options Option 3: Ventilation arrangement using large cupboard with min. 40mm overhang Directing warm air straight into the room. Must be installed Inlet Must be installed Extra Inlet vent option Option 4: Ventilation arrangement using small cupboard with min.
- Page 8 Ventilation installation instructions Option 5: Ventilation arrangement if using a large cupboard with less than 40mm, or no overhang. Directing warm air into the kick space & out through a vent grille. Must be installed Inlet Both must be installed Extra Inlet vent option Option 6: Ventilation arrangement if using small cupboard with less than 40mm, or no...
- Page 9 Installation - Ancillary components, Booster If supplied as part of the kit mount the Booster as follows: 10⁰ 15⁰ Connect the braided hoses to the Booster: Do not over tighten hose connections. Braided hoses supplied cannot be lengthened. Cold water into Booster, connect to Command Centre Hot water out of Booster, connect to Command Centre...
- Page 10 Installation - Ancillary components, Limescale filter UK only If installing a limescale filter, set the bypass valve (Rear of the Command Centre). Scan the QR Codes & read the filter instructions Bypass valve General installation arrangement instructions Make sure the braided hose and adaptor arrangement for the mains water supply are installed as follows: 90º...
- Page 11 BC Home, BC H Home, BC20, BC20 H, BC30, BC30 H Installation Scan the QR Code & read Install the HydroTap in order the instructions Install the vent mounting plate on the cupboard floor, scan the QR Code & read the instructions. Ventilation Installation Install Rail Instructions...
- Page 12 BC Home, BC H Home, BC20, BC20 H, BC30, BC30 H Commissioning Commission the HydroTap in order Commissioning process, follow screen prompts, scan HydroTap Clean QR for more information. If cupboard temperatures exceed 35 C additional ventilation HydroTap Clean will be required. To use the HydroTap, scan the User Guide QR Code &...
- Page 13 BC40, BC40 H, BC60, BC60 H, BC100, BC100 H Installation Scan the QR Code & read Install the HydroTap in order the instructions Install the vent mounting plate on the cupboard floor, scan the QR Code & read the instructions. Ventilation Installation Install Rail Instructions...
- Page 14 BC40, BC40 H, BC60, BC60 H, BC100, BC100 H Commissioning Commission the HydroTap in order Commissioning process, follow screen prompts, scan HydroTap Clean QR for more information. HydroTap Clean If cupboard temperatures exceed C additional ventilation will be required. Turn on water supply &...
- Page 15 Notes Quick Reference Installation Guide 810006 v1.00 08.24 G5 BC Quick Reference Installation Guide...
- Page 16 Refer to User Guide for operation and maintenance. As Zip policy is one of continuous product improvement, changes to specifications may be made without prior notice. Images in this booklet have been modified and may not be true representations of the finished goods.
