Wiring Diagrams - Trane IntelliPak 3 with Symbio 800 Installation, Operation And Maintenance Manual

Wiring Diagrams

Table 77. Wiring diagram matrix
Description
Number
Power
1213-4995 POWER SCHEMATIC, 20T-75T - AIRFLOW AND CONTROLS
1213-4996 POWER SCHEMATIC, 20T-75T - AIRFLOW AND CONTROLS W/ VFD BYPASS
POWER SCHEMATIC, 40T-75T - REFRIGERATION
1213-4997
POWER SCHEMATIC, 40T-75T - REFRIGERATION WITH COMPRESSOR VFD
1213-4998
POWER SCHEMATIC, 40T-75T - REFRIGERATION WITH COND FAN VFD
1213-4999
POWER SCHEMATIC, 40T-75T - REFRIGERATION WITH COMPRESSOR AND COND FAN VFD
1213-5000
POWER SCHEMATIC, 20T-30T - REFRIGERATION
1213-5001
POWER SCHEMATIC, 20T-30T - REFRIGERATION WITH COMPRESSOR VFD
1213-5002
POWER SCHEMATIC, 20T-30T - REFRIGERATION WITH COND FAN VFD
1213-5003
1213-5004 POWER SCHEMATIC, 20T-30T - REFRIGERATION WITH COMPRESSOR AND COND FAN VFD
Controls
CONTROLS SCHEMATIC, 20T-75T - FIELD WIRING AND CONDENSER CONTROLS
1213-4631
CONTROLS SCHEMATIC, 20T-75T - REFRIGERATION SYSTEMS
1213-2582
CONTROLS SCHEMATIC, 20T-75T - REFRIGERATION SYSTEMS WITH VARIABLE SPEED COMPRESS
1213-5007
CONTROLS SCHEMATIC, 20T-75T - REFRIGERATION SYSTEMS WITH VARIABLE SPEED COND FAN
1213-2584
CONTROLS SCHEMATIC, 20T-75T - REFRIGERATION SYSTEMS WITH VSC AND VCF
1213-2585
CONTROLS SCHEMATIC, 20T-75T - REFRIGERATION SYSTEMS
1213-5005
1213-5006 CONTROLS SCHEMATIC, 20T-75T - REFRIGERATION SYSTEMS WITH VARIABLE SPEED COND FAN
1213-4630 CONTROLS SCHEMATIC, 20T-75T - RETURN SECTION #1
CONTROLS SCHEMATIC, 20T-75T - RETURN SECTION 2 OF 2
1213-5008
Gas Heat
1213-2827 SCHEMATIC/LAYOUT - STAGED GAS HEAT - 250 & 350 MBH
1213-2828 SCHEMATIC/LAYOUT - STAGED GAS HEAT - 500 MBH
1213-2829 SCHEMATIC/LAYOUT - STAGED GAS HEAT - 850 & 1200 MBH
SCHEMATIC/LAYOUT - MODULATING GAS HEAT - 250, 350 MBH STD
1213-2830
1213-2831 SCHEMATIC/LAYOUT - MODULATING GAS HEAT - 250 & 350 MBH ULTRA/500 MBH STD
1213-2832 SCHEMATIC/LAYOUT - MODULATING GAS HEAT - 500 MBH ULTRA
1213-2833 SCHEMATIC/LAYOUT - MODULATING GAS HEAT - 850 & 1200 MBH STD/ULTRA
Electric Heat
1213-2835 SCHEMATIC - ELECTRIC HEAT - 30KW - 480V/600V
1213-2836 SCHEMATIC - ELECTRIC HEAT - 30KW - 208V/240V
1213-2837 SCHEMATIC - ELECTRIC HEAT - 60KW - 480V/600V
SCHEMATIC - ELECTRIC HEAT - 60KW - 208V/240V, 120KW & 150KW - 480V/600V
1213-2838
1213-2839 SCHEMATIC - ELECTRIC HEAT - 90KW - 480V/600V
SCHEMATIC - ELECTRIC HEAT - 90KW - 208V/240V, 190KW - 480V/600V
1213-2840
1213-2841 SCHEMATIC - ELECTRIC HEAT - 120KW - 208V/240V
1213-2842 SCHEMATIC - ELECTRIC HEAT WITH SCR MODULATING - 30KW - 480V
1213-2843 SCHEMATIC - ELECTRIC HEAT WITH SCR MODULATING - 30KW - 208V/240V
1213-2844 SCHEMATIC - ELECTRIC HEAT WITH SCR MODULATING - 60KW - 480V
SCHEMATIC - ELECTRIC HEAT WITH SCR MODULATING - 60KW - 208V/240V, 120KW & 150KW - 480V
1213-2845
1213-2846 SCHEMATIC - ELECTRIC HEAT WITH SCR MODULATING - 90KW - 480V
RT-SVX080A-EN 159
