Trane IntelliPak 3 with Symbio 800 Installation, Operation And Maintenance Manual page 155

Table 73. Value for Parameter 4-14 (Motor Speed High Limit (Hz)
Digit# 3,4,5 Unit Digit# 15 Fan
Tonnage Size
A,B
F20,F25,F30 E,F
G
C
F40,F50,F55
F
J,K
H
F60,F70,F75
M
Table 74. Condenser fan VFD programming parameters
Descrtiption
ID
language
0-01
Regional Settings
0-03
Grid Type
0-06
[Hand on] Key on LCP
0-40
Motor Power (kW/HP)
1-20
Motor Voltage (V)
1-22
Motor Frequency (Hz)
1-23
Motor Current (A)
1-24
Motor Nominal Speed (RPM)
1-25
Flying Start
1-73
Min Speed for function at Stop (Hz)
1-82
1-90 Motor Thermal Protection
DC Hold/Preheat Current (%)
2-00
DC Braking time (s)
2-02
2-10 Brake Function
Maximum Reference (Hz)
3-03
3-15 Reference 1 Source
3-16 Reference 2 Source
3-17 Reference 3 Source
Ramp 1 Ramp Up Time (s)
3-41
Ramp 1 Ramp Down Time (s)
3-42
RT-SVX080A-EN
Digit# 16 = 1 (4 Digit# 16 =2 (6
Pole) Pole)
[119] [120]
[92] [120]
[82] [120]
[100] [120]
[92] [120]
[75] [114]
[82] [120]
[68] [103]
[102] 200-240V/60Hz for 200 & 230V/60Hz units
[12] 380-440V/50Hz for 380 & 415V/50Hz supply
For IT Grid (no ground connections) or Corner grounded Delta power supply systems, the
applicable voltage/Hz and IT-Grid or Delta should be selected.
1-20=[7]
1-20=[8]
Parameter Setting
[0] English US
[1] North American
Set to applicable unit power supply
[122] 440-480V/60Hz for 460V/60Hz units
[132] 525-600V/60Hz for 575V/60Hz units
[0] Disabled
Per Motor Nameplate KW- HP
[7] 0.75kW - 1.0HP
[8] 1.1kW - 1.5HP
[200] 200V [230] 230V
[60] 60 Hz
[4.1] 4.1A [4.1] 4.1A
[5.4] 5.4A [5.4] 5.4A
[1140] 1140RPM
[1] Enabled
0.1
[4] ETR Trip1
[0] 0%
[0] 0s
[2] AC Brake is Active
[60] 60Hz
[1] Local bus reference
[0] No function
[0] No function
[10] 10s
[10] 10s
Service and Maintenance
[460] 460V [575] 575V
[1.8] 1.8A [1.4] 1.4A
[2.7] 2.7A [2.05] 2.05A
155
