Sequence of Operation
Figure 49. Modbus Device Addressing — Rebuild
Modbus Addresses
Modbus Device
Compressor 1A
Condenser Fan 1
Condenser Fan 2
Supply Fan 1
Supply Fan 2
Relief Fan 1
Relief Fan 2
Relief Fan 3
Modulating Gas Heat
Staged Gas Heat
Refrigerant Leak Detector A
Refrigerant Leak Detector B
Refrigerant Leak Detector C
Refrigerant Leak Detector D
100
Modbus Address Tool Display Name
Not Applicable
Not Applicable
Not Applicable
Not Applicable
Not Applicable
VFD Relief Fan 1
VFD Relief Fan 2
VFD Relief Fan 3
Not Applicable
Not Applicable
Refrigerant Leak Sensor A
Refrigerant Leak Sensor B
Refrigerant Leak Sensor C
Refrigerant Leak Sensor D
RTU Address
3
5
6
7
8
9
10
11
20 (always manifold 1)
21 (manifold 1)
22 (manifold 2)
51
52
53
54
RT-SVX080A-EN
