- Page 1 -- UAG-AC -- (WITH THE HOOP REJUVENATOR™) Installation Instructions Call Jaypro Sports Equipment at 1-800-243-0533 during regular business hours for technical support. www.jaypro.com Rev: C Page 1 of 16...
- Page 2 JAYPRO SPORTS UAG-AC (RECTANGULAR ACRYLIC BACKBOARD) IMPORTANT NOTICE: 1) INSPECT FOR DAMAGE. REPORT ALL DAMAGES TO TRUCKING COMPANY. 2) BEFORE EACH USE CHECK EQUIPMENT FOR PROPER CONNECTING HARDWARE AND STRUCTURAL INTEGRITY. REPLACE DAMAGED OR MISSING HARDWARE IMMEDIATELY. 3) USE OF THIS EQUIPMENT OTHER THAN INTENDED, MAY BE HAZARDOUS.
- Page 3 IMAGE DESCRIPTION DOUBLE RIM ULTIMATE BREAKAWAY GOAL P/N: UBG-500F 42” x 72” RECTANGULAR ACRYLIC BACKBOARD P/N: ACRB-72 4-1/2” OD BAND CLAMP P/N: BRC45 1/2”-13 x 1-1/4” CARRIAGE BOLT, SS P/N: HB5036 3/8”-16 HEX NUT, SS P/N: HN2896 3/8”-16 NYLON LOCK NUT, ZP P/N: HN265 1/2”-13 HEX NUT, SS P/N: HN5037...
- Page 4 IMAGE DESCRIPTION 3/8”-16 x 1-3/4” HEX BOLT, SS P/N: HS5246 3/8”-16 x 1” HEX BOLT, SS P/N: HS5247 5/8”-11 x 4-1/2” HEX BOLT, SS P/N: HS5268 3/8”-16 x 1-1/2” HEX BOLT, SS P/N: HS5272 3/8”-16 x 3” HEX BOLT, SS P/N: HS5273 1/2”...
-
Page 5: Tools Required
IMAGE DESCRIPTION 3/8” WASHER, SS P/N: HW2151 5/8” WASHER, SS P/N: HW5057 1/4”-14 x 3/4” SELF TAP HEX SCREW, SS P/N: HS5191 IMAGE DESCRIPTION TOOLS REQUIRED: (1) 9/16” Socket Wrench and Box Wrench (1) Anti-seize Compound (1) 3/4” Socket Wrench and Box Wrench (1) Scaffolding, Lull or Lift (1) 15/16”... - Page 6 Upright Installation: 1. Check local building codes before starting the footing, as building codes may vary. Local building codes should be adhered to if requirements are greater than those outlined here. 2. Dig a hole 36 inches square or round to a depth on 54 inches, pour an 6 inch footing and allow fully curing or placing upright on two 6 inch concrete blocks.
- Page 7 Upright Assembly: 1. Attach the H-Frame gooseneck bracket together as shown (figure 5). REF 3” OUTSIDE TO OUTSIDE OF PLATE UAG GOOSENECK UPRIGHT Plan View 3/8”-16 NYLON LOCK NUT, ZP 3/8” WASHER, SS REF 5/8” HOLE H-FRAME GOOSENECK BRACKET 3/8” WASHER, SS 3/8”-16 x 1-1/2”...
- Page 8 Frame Assembly: 1. Attach the T-Frame to the H-Frame slot channel with 1/2” carriage hardware as shown (Figure 1). Do not tighten. 2. Slide the T-Frame on the H-Frame slot channel till the bottom of both frames are at a distance of 9-7/16” (Figure 2) and tighten the carriage bolts down. 3.
- Page 9 CRITICAL 3” INSIDE TO INSIDE OF PLATE Figure 4 ” 9-7/16” CRITICAL Figure 2 H-FRAME BOARD BRACKET 3/8”-16 x 1-1/2” HEX BOLT, SS 3/8” WASHER, SS Figure 3 3/8”-16 NYLON LOCK NUT, ZP 3/8” WASHER, SS Rev: C Page 9 of 16...
- Page 10 Frame Assembly Attachment: 1. Once the H-Frame board brackets is on the H-Frame gooseneck bracket. Tighten the board bracket hardware (Figure 7). 2. Lift and attach the frame assembly to the mounting plates using 5/8” hardware. Adjust and frame assembly plumb to the playing surface. Do not over tighten. 3.
- Page 11 3/8” WASHER & 3/8”-16 NYLON LOCK NUT, ZP SUPPORT BRACE 3/8” WASHER, SS 3/8”-16 x 1” HEX BOLT, SS 4-1/2” OD BAND CLAMP Figure 8 Rev: C Page 11 of 16...
- Page 12 3/8”-16 x 1-1/2” HEX BOLT, SS 3/8” WASHER, SS 3/8”-16 NYLON LOCK NUT, ZP 3/8” WASHER, SS Important: Maintain the plumb to the playing surface! DRILL 2 PILOT HOLES INTO BAND CLAMP & UPRIGHT PIPE NEAR THE OPENING CLAMP. 1/4”-14 x 3/4” SELF TAP HEX SCREW, SS Figure 9 Rev: C Page 12 of 16...
- Page 13 3/8”-16 NYLON LOCK NUT, ZP 3/8” WASHER, SS Important: Maintain the plumb to the playing surface! Using the 4 holes in the outer plates as a template to drill thru to the other side of the plate and lock the plumb in place with 4 set of 3/8”...
- Page 14 Board Assembly: 1. Attach the appropriate brace mounting bracket to the back of the backboard. The bracket will depend on the backboard ordered. The brackets will either be included with the backboard or board specific in the general kit. 3/8”-16 NYLON LOCK NUT, ZP 3/8”...
- Page 15 3/8”-16 NYLON LOCK NUT, ZP 3/8” WASHER, SS 3/8” WASHER, SS 3/8”-16 x 1-3/4” HEX BOLT, SS Rev: C Page 15 of 16...
- Page 16 Maintenance: Thoroughly inspect the system at least twice a year check all hardware for tightness and wear. Inspect the system for any surface rust. Brush off and protect rusted areas with a Rustoleum type zinc spray. Check the height and plumpness of the system. Carefully adjust if needed. LOOSEN THESE FOUR BOLTS AND SLIDE THE ENTIRE BACKBOARD UP OR DOWN.
