-- TSP-200 --
(THE PARK OUTDOOR BASKETBALL SYSTEM)
Installation Instructions
!
!
WARNING
DO NOT ATTEMPT TO ASSEMBLE
THIS SYSTEM WITHOUT CAREFULLY
READING AND FOLLOWING ALL
I N S T R U C T I O N S . B E G I N B Y
I D E N T I F Y I N G A N D T A K I N G
INVENTORY OF ALL PARTS USING
T H E P A R T S L I S T P R O V I D E D .
Call Jaypro Sports Equipment at 1-800-243-0533
during regular business hours for technical support.
www.jaypro.com
Keep this instruction manual in case you have to contact the manufacturer for replacement parts.
Rev: C
[Type text]
Page 1 of 15
Advertisement
Related Manuals for Jaypro Sports TSP-200
Summary of Contents for Jaypro Sports TSP-200
- Page 1 INVENTORY OF ALL PARTS USING T H E P A R T S L I S T P R O V I D E D . Call Jaypro Sports Equipment at 1-800-243-0533 during regular business hours for technical support. www.jaypro.com Keep this instruction manual in case you have to contact the manufacturer for replacement parts.
-
Page 2: Required Tools
REQUIRED TOOLS 6. 1-1/16” Wrench 1. 2 Adjustable Wrenches 2. MM / Inch Socket Set 7. Tape Measure 3. 17MM Wrench 8. Hammer or Mallet 4. 3/4” Wrench 9. Lithium Grease 5. 15/16” Wrench 10. Carpenter's Level 16. 3/4” x 36” Long Rebar 7. - Page 3 JAYPRO SPORTS TSP-200 THE PARK ITEM IMAGE DESCRIPTION 6” x 6” x 106-1/4” LONG SQUARE UPRIGHT POST OUTRIGGER SUPPORT ARM ACTUATOR MOUNTING PLATE ACTUATOR (P/N: TSP201) ITEM IMAGE DESCRIPTION Rev: C [Type text] Page 3 of 15...
- Page 4 ITEM IMAGE DESCRIPTION FOOTING PLATE 42” x 72” ACRYLIC BACKBOARD (P/N: ACRB-72M) PAIR OF BACKBOARD EDGE PADDING INCLUDES MOUNTING HARDWARE (P/N: EP-46) RIM GASKET UNIVERSAL BREAKAWAY RIM INCLUDES MOUNTING HARDWARE (P/N: GBA-548) ITEM IMAGE DESCRIPTION Rev: C [Type text] Page 4 of 15...
- Page 5 ITEM IMAGE DESCRIPTION LYNCH PIN WITH ROUNDED RETAINER SAFELY BAR J-BOLT WITH PRE-ASSEMBLE HARDWARE 2X M16 HEX NUT 2X M16 WASHER 1X M16 FLANGE NUT M16 x 200mm LONG HEX BOLT M16 x 130mm LONG HEX BOLT M16 WASHER M16 LOCK WASHER M16 HEX NUT ITEM IMAGE...
- Page 6 ITEM IMAGE DESCRIPTION M16 NYLON LOCK NUT M18 x 318mm LONG HEX BOLT M18 x 240mm LONG HEX BOLT M18 WASHER M18 NYLON LOCK NUT M12 x 55mm LONG HEX BOLT M12 x 75mm LONG HEX BOLT M12 WASHER M12 BLACK FENDER WASHER ITEM IMAGE DESCRIPTION...
- Page 7 2) USE OF THIS EQUIPMENT OTHER THAN INTENDED, MAY BE HAZARDOUS. 3) ALTERATION OR MODIFICATION OF THIS EQUIPMENT MAY BE HAZARDOUS AND RESULT IN INJURY. FOR REPAIR OR REPLACEMENT, CONTACT YOUR DEALER OR JAYPRO SPORTS. Rev: C [Type text] Page 7 of 15...
- Page 8 INSTALLATION TIP / REFERENCE OVERALL VIEW Rev: C [Type text] Page 8 of 15...
- Page 9 Footing: NOTE: Before digging, call to locate any buried utility lines. a. Dig a hole 48" deep x 36" across. The edge of the hole should be flush with the edge of the playing surface. If you live in an area where heavy frost can occur, it may pose a problem, consult your local building inspector to determine the appropriate hole depth.
- Page 10 Install Post: Carefully position the post onto the ground anchor kit, install hardware as shown. NOTE: Do not tighten the nuts all the way down to the plate at this time. M16 Hex & Washers M16 Washers Install Actuator Mounting Plate: Carefully position the post onto the ground anchor kit, install hardware as shown.
- Page 11 Install Outrigger & Support Arms: Lift outrigger over top of post & lower into position. Apply a small amount of grease to the hex bolt. NOTE: Do not tighten the nuts all the way down to the plate at this time. M18 Nylon Lock Nut &...
- Page 12 Install Actuator: Apply a small amount of grease to the hex bolt. Assemble as shown. M18 Nylon Lock Nut & Washer M18 Hex Bolt & Washer 318MM Long 16MM Hex Bolt & Washer 16MM Nylon Lock Nut & Washer 130MM Long Rev: C [Type text] Page 12 of 15...
- Page 13 Install Board: Using actuator, lower outrigger to the lowest position. Assemble as shown. NOTE: Do not tighten the nuts all the way down to the plate at this time. 12MM Nylon Lock Nut & Washer Black fender washer 12MM Hex & Washer 55MM Long Plug hole with M10 hardware.
- Page 14 Install Rim / Edge Padding: Assemble rim and edge padding onto the backboard. Remove rim cover if applicable Hardware provided with rim, refer to goal instructions Rim gasket Hardware provided with goal, refer to rim instructions Final Adjustments / Plumb Unit: With the rim set at the 10 FT height.
- Page 15 Labels / Pad: With the rim set at the 10 FT height. Apply labels for height as shown below. Strap the two piece post pad onto the post. Lower Lower Raise Raise Peel away the non-adhesive backing. Maintenance: Lubricate moving joints w/ lithium spray Inspect all hardware for war &...
