Jaypro Sports PVB Series Installation And Operating Instructions Manual
Steel/featherlite collegiate net system
Hide thumbs
Also See for PVB Series:
- Installation and operating instructions manual (12 pages) ,
- Installation and operating instructions manual (10 pages)
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Jaypro Sports PVB Series
Summary of Contents for Jaypro Sports PVB Series
- Page 1 PVB S AYPRO ERIES OLLEGIATE YSTEM Installation and Operating Instructions Applicable Part Numbers/Models: PVB-1500: Steel Collegiate Net System PVB-4500/PVB-5000: Featherlite Collegiate Net system JSL-Inst040 www.jayprosports.com...
-
Page 2: Table Of Contents
PVB Series Collegiate Net System Instructions Table of Contents Safety ......................2 Specifications ....................2 Introduction ....................2 Required Tools ....................3 Included Hardware & Components ............4 5.1 System Components ................4 5.2 Hardware ....................5 Assembly ......................6 Maintenance .................... -
Page 3: Safety
If you require additional information or support to install or operate your volleyball system, please contact the Jaypro Sports customer support team, Monday through Friday, 8:30AM to 5:00 PM (EST), at 1-800-243-0533. NCAA and NFHS rules require that the upright standards must be installed at least 3’3”... -
Page 4: Required Tools
Figure 3-1: Correct Ground Sleeve Dimensions Required Tools Before continuing, please verify that you have the following tools required to complete the installation and setup of your PVB Series Collegiate Net System. Adjustable wrench ▪ Hex keys – 3/16”, 5/16”... -
Page 5: Included Hardware & Components
Before continuing, please open all packages to verify that you have all the required hardware for installation and setup. If any of the following items are missing, contact the Jaypro Sports customer support team, Monday through Friday, 8:30AM to 5:00 PM (EST), at 1-800-243-0533. -
Page 6: Hardware
PVB Series Collegiate Net System Instructions Figure 5-6: Antennae and Net Tapes (VBA-4, 1 pair) Figure 5-7: Anchor Strap (PVB-604, 1X) 5.2 Hardware Figure 5-8: Button Head Cap Screw (HS5098, 1X) Figure 5-9: Button-Head Cap Screw (HS5201, 1X) Figure 5-10: Acorn Nut (HN809, 2X) -
Page 7: Assembly
PVB Series Collegiate Net System Instructions Assembly WARNING: Uprights are heavy. Do not attempt to lift or install without assistance. 1. Install each upright into the ground sleeves. 2. Follow instructions included with winch to set the winch clamp to the correct upright diameter (3-1/2”). - Page 8 PVB Series Collegiate Net System Instructions 5. Install the anchor strap to the upright without the winch (Figure 6-2). Figure 6-2: Install anchor strap. 6. Set the height of the uprights using the installed height adjust pin (Figure 6-3). WARNING: Do not attempt to remove the height adjuster pin if the net is under tension.
- Page 9 PVB Series Collegiate Net System Instructions Figure 6-3: Set upright height. 7. Attach one end of net to anchor strap, then attach other end to winch strap (Figure 6-4). For alternative net PVBN-5, see net install from this point. Figure 6-4: Attach net to straps.
-
Page 10: Maintenance
13. Install pads around each upright. Maintenance Your PVB Series Collegiate Net System is designed to provide years of play; however, it is recommended that the components be inspected at least once every season, for signs of excessive wear. Key areas to inspect include (but are not limited to): Strap webbing ▪...
