Stratus SAE-P48PC Installation, Operation And Maintenance Manual

Stratus boxed steel construction & sleeve containment 8,000lbs capacity manual release 4 post mobile compact storage parking car lift

Advertisement

Quick Links

5881 Imperial Loop Dr.
College Station, Tx USA
Telephone:(512) 640-9896
stratusautoequip.com
Safety - Installation - Operation - Maintenance
Stratus Boxed Steel Construction & Sleeve Containment 8,000
LBS Capacity Manual Release 4 Post Mobile Compact Storage
IMPORTANT NOTE:
1.
Save these instructions!
2.
This equipment should not be installed, operated or repaired without first reading the instructions.
Failure to follow the instructions and safety can result in serious injury or death.
3.
Electricity should be hooked up by a certified electrician.
4.
Do NOT use equipment beyond its rated capacity.
5.
Keep manual near lift for reference
6.
By proceeding with installation and operation, you agree that you fully understand the contents of
this manual and assume full responsibility for product use.
7.
Only Operate this lift if it can be done so safely.
Parking Car Lift: SAE-P48PC
Model: P48PC
Manual SAE-P48PC— Revision A1 — May 2024
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SAE-P48PC and is the answer not in the manual?

Questions and answers

Summary of Contents for Stratus SAE-P48PC

  • Page 1 College Station, Tx USA Telephone:(512) 640-9896 stratusautoequip.com Safety - Installation - Operation - Maintenance Stratus Boxed Steel Construction & Sleeve Containment 8,000 LBS Capacity Manual Release 4 Post Mobile Compact Storage Parking Car Lift: SAE-P48PC Model: P48PC Manual SAE-P48PC— Revision A1 — May 2024...
  • Page 2 Introduction This manual is designed to help customers use Stratus P48PC 4 post parking lift. This is a mid rise, with an open center that provides full under vehicle access. This lift comes with a capacity of 8,000 LBS. Stratus recommends keeping this manual within reach of the lift for anyone who is to use or service the machine.
  • Page 3 Liability Stratus Auto Equipment assumes no liability for damages resulting from: •Use of the product for purposes other than those described in this manual. •Modifications to the equipment without prior, written permission from Stratus Auto Equipment •Injury or death caused by modifying, disabling, overriding, or removing safety features.
  • Page 4 Stratus Auto Equipment's website. Not all of Stratus Auto Equipment lift models meet the standards as prescribed by ANSI/ALI ALCTV-(current edition) or ANSI/UL 201. Consult www.autolift.org...
  • Page 5: Unit Information

    Unit Information Be sure to document the Model Number, Serial Number, and Date of Manufacture from the label on your unit below. This information is required for part or warranty issues.
  • Page 6 Index Important Safety Instructions ............7~11 1.1 Important Notices 1.2 Qualified Personnel 1.3 Warning Signs 1.4 Safety Instructions 1.5 Labels 1.6 Sound Level 1.7 Training 1.8 Special Reminder 2. Overview of the Lift...................12 2.1 General Description 2.2 Measurements 3. Installation Instructions..............13~16 3.1 Precautions for Installation 3.3 Installation 4.
  • Page 7: Important Safety Instructions

    Important Safety Instructions 1.1 Important Notices Make sure to pay careful attention to the label of the lifting capacity attached on the lift and never try to lift cars above the lifting capacity labeled. Read this manual carefully before operating the machine so as to avoid personnel injury Users are not permitted to make any modification to the control or mechanical unit 1.2 Qualified Personnel...
  • Page 8 1.4 Safety Instructions Make sure that you have read the User’s Manual completely, including relevant instructions on installation, operation, and safety before operating the lift. This lift is designed for lifting vehicles 8,000 LBS and under. Any other use may result in damage of the lift or injury to personnel.
  • Page 9 Keep areas well lit. Keep loads balanced on the lift platforms. Clear the area immediately if a vehicle is in danger of falling off the lift. DO NOT ATTEMPT TO CATCH A FALLING VEHICLE! Make sure there are no obstacles under the vehicle before lowering it If the lift will be left unused for a long period of time, it is recommended that the user disconnects power, empties the oil tank, and lubricates any moving parts with hydraulic Attention: For environment protection, please dispose of the used oil in a proper way.
  • Page 10 CAUTION Only trained personnel is allowed to use the lift. Read the entire manual before operating Never try to raize the vehicle exceding lift capacity Make sure you meet all safety requirements before you start working under the vehicle Surrounding of lift will remain clear when raising or lowering The manufacturer and distributor will not take any responsibility if user does not follow the...
  • Page 12 *Warning label pictographs used with permission of the Automotive Lift Institute.
  • Page 13 1.6 Sound Level The sound emitted from the lift should not exceed 75 DB. 1.7 Special Reminder The newly installed lift can NOT directly lift vehicle, and should be raised to the highest point then lowered to the lowest point 2-3 times repeatedly without any load to bleed the air out from the hydraulic hose and cylinders to ensure the lift runs smoothly 1st time use of the lift with a load after bleeding air out of the the hydraulic hose and cylinders should follow the steps below...
  • Page 14 Overview of the Lift 2.1 Technical data Lifting Model Lifting Time Lifting Height Power Supply Capacity SAE- P48PC 8,000 LBS ~50 sec 70 7/8" 110V, 1ph 2.2 Measurements...
  • Page 15: Installation Instructions

    Installation Instructions 3.1 Precautions for Installation The joints of the oil hose must be firmly connected in order to avoid leakage All bolts should be firmly screwed up Do not place any vehicle on the lift during trial running 3.2 Installation Remove the accessory packages, and take the parts out of their packaging.
  • Page 16 Once each cross beam has been installed on the posts, proceed to stand up the posts, and have the cross beam at the first set of locks With the posts spaced accordingly, place the platforms on the cross beams, and secure with the bolts provided.
  • Page 17 With the cables routed through the ramp and posts, secure them to the post caps with the nuts provided. Next, move on to installing the locking mechanism Use the bolts provided to secure the linkages with the long link going on top, and the short link going on the bottom.
  • Page 18 Next, assemble the mobile caster kit with the bolts provided. With the mobile caster kit assembled, proceed to install one onto each post.
  • Page 19 If the lift is used while the vehicle’s center of gravity is not positioned midway between the rising platforms, Stratus, as well as our dealers will not bear any responsibility for any consequence resulted thereby.
  • Page 20 4.3 Emergency lowering The safety lock is not engaged: Tie up the safety teeth on both sides with rope; pull upward on the rope to make sure the safety teeth are unlocked. Once the safety teeth are unlocked, manually loosen the core of the electro-magnetic valve on the pump assembly.
  • Page 21: Frequently Asked Questions

    Frequently Asked Questions What thickness of concrete do you recommend? We recommend 6-12 inches of reinforced concrete that has cured for at least 30 days. What is the recommended PSI for the concrete? We recommend a psi of 3,000 What kind of oil do I use? AW32 or AW46 hydraulic oil Does this lift come with a plug? The lift does not come with a plug, you will need to get a 110V, or 220V...
  • Page 22: Maintenance

    Maintenance Daily Pre-operation Check hydraulic connections and hoses for leaks Check mechanical locks audibly and visually while in operation Check arm locks Check bolts, nuts, and screws are tight Every 1 Month Check all cable connections, pins and bolts to insure proper mounting Inspect all anchor bolts and retighten if necessary Check columns for square-ness and plumb Check equalizer cable tension, adjust if necessary...
  • Page 23: Warranty

    Warranty 5 years lifting structure Post, Cross Bar, Carriage, Arms, Safety Locks, Safety Lock Pins, Arm Pin, Runway 3 years hydraulic Power Unit/Station, Cylinder 2 years electrical Electrical, Buttons, Solenoid, Limit Switch 1 Year Balance Cable, Safety Lock Release Cable, Safety Covers, Support Bar, Ramps, Hydraulic Hose, Fittings No Warranty Door Guard, Rubber Pads, Truck Adaptors **Parts only!! Labor costs for someone to install replacement parts are NOT covered.
  • Page 24 Parameters Model P48PC Rated Lifting Capacity 8,000 LBS Minimum Height 5 5/16" Lifting Height 70 7/8" Overall Length Without Ramps 176 7/8" Platform Length With Ramps 200 1/4" Platform Width 18 11/16" Motor Parameters 110V/220V Hydraulic Oil AW32 or AW46 Features Boxed Steel Construction &...
  • Page 25: Exploded View

    Exploded View Pump: Description Description Motor Oil Hose Tie-In Hydraulic Block Electrical Unloading Valve Overflow Valve Single Way Valve Fitting Gear Pump Cushion Valve Oil Tank Absorbing Oil Pipe Oil Tank Cover Oil Filer Oil Back Pipe Throttle Valve...
  • Page 26 Exploded View Lift: Description Description Power-side column Washer D.16 - GB/T97.1 Off-side column Locking washer D.16 - GB/T97.1 Power-side platform Screw M16X35 - GB/T5783 assembly Off-side platform Washer D.10 - GB/T97.1 assembly Transverse beam Locking washer D.10 -GB/T93 assembly...
  • Page 27 Description Description Screw M10X25 - Caster Kit GB/T5783 Drive on ramp Hydraulic Power Unit assembly Wheel stop plate Handle release lever Screw M16X30 - Extension Lever GB/T5783 Connection Rod Knob Cover Self locking nut M10 Safety Release lever Ankle Plate Rubber pad Steel cable A Steel cable B...
  • Page 28 Exploded View Traverse Beam Description Description Latch release rod B Knob M19X33 Latch release rod A Nut M12 Coupler Nut M8 - left handed Spacer Nut M8 Long stud Self-locking nut M8 Short stud Screw M8X30 Bearing M8 - left Right latch handed Bearing M8...
  • Page 29 Exploded View Traverse Beam Description Description Transverse beam Spacer Shaft 1 Nylon roller Shaft 2 Cable pulley Bush Washer Safety pawl A Shaft 3...
  • Page 30 Description Description Bush Nut M8 - GB/T889.1 Protective Plate Bush bearing Safety pawl B Manual release unit Bush 3520 Short rod Seeger D.18 Long rod Seeger D.16 Nut M12 Seeger D.10 Screw M8X25 Screw M6X16 - Locking washer D.8 - GB/T93 GB/T5783 Washer D.6 - GB/T97.1 Seeger D.25 - GB/T894.1...
  • Page 31 Exploded View Power-side runway Description Description Power-side platform Pulley shaft Washer Pulley shaft Washer Spacer Cable pulley Shaft Bush 3520 Greaser M8X1...
  • Page 32 Description Description Screw M8X16 - Screw M8X25 - GB/T5783 GB/T5783 Washer D.8 - GB/T97.1 Nut M8 - GB/T889.1 Locking washer D.8 - Nut M24 - GB/T6170 GB/T93 Hydraulic cylinder Pin 5X50 - GB/T91 Clamp Protection board Cable holder Screw M8X20 - GB/T70.1 Slider...
  • Page 33 Exploded View Hydraulic line Description Description Hydraulic power unit Cylinder liner Hydraulic cylinder Piston shaft Valve housing Piston 90° bulkhead fitting 1/4 Cylinder guiding cover Hydraulic hose 1/4 Cover L=1440 Hydraulic hose 1/4 Scraper 25X33X4.5/6 L=2000 Spring Sealing ring 25X33X5 Restrictor Guide ring 25X15X2.5 Washer 1/4...
  • Page 34 Automotive Lift Institute Store You probably checked the ALI’s Directory of Certified Lifts(www.autolift.org/ali-directory-of- certified-lifts/) before making your most recent Lift purchase, but did you know the ALI Store (www.autolift.org/ali-store/) offers a wide variety of professional, easy-to-use, and reasonably priced training and safety materialsthat will make your garage a safer place to work? The ALI Store is your trusted source for workplace safety! Visit today and get the training and materials you need to worksafely:...
  • Page 35 Special Notes Environmental damage : Only appropriately trained personnel may dismantle and dispose of the unit. Dismantling: To dismantle the product, proceed as follows: ELECTRICAL HAZARD! When carrying out any decommissioning and dismantling work on the unit, switch off all power supply connections, ensure they cannot be switched on unintentionally and verify that they have been disconnected.
