Safety - Installation - Operation - Maintenance
Stratus Pro Asymmetric & Symmetric 2-in-1 Clear Floor Direct
Drive 10,000 LBS Capacity Single Point Manual Release Car Lift
IMPORTANT NOTE:
1.
Save these instructions!
2.
This equipment should not be installed, operated or repaired without first reading the instructions.
Failure to follow the instructions and safety can result in serious injury or death.
3.
Electricity should be hooked up by a certified electrician.
4.
Do NOT use equipment beyond its rated capacity.
5.
Keep manual near lift for reference
6.
By proceeding with installation and operation, you agree that you fully understand the contents of
this manual and assume full responsibility for product use.
7.
Only Operate this lift if it can be done so safely.
Sales & Showroom
5881 Imperial Loop Dr.
College Station, Tx USA
Telephone:(512) 640-9896
SAE-C10A
Model: C10A
Manual SAE-C10A— Revision A1 — June 2024
1
Advertisement
Related Manuals for Stratus SAE-C10A
Summary of Contents for Stratus SAE-C10A
- Page 1 Telephone:(512) 640-9896 Telephone:(512) 640-9896 stratusautoequip.com Safety - Installation - Operation - Maintenance Stratus Pro Asymmetric & Symmetric 2-in-1 Clear Floor Direct Drive 10,000 LBS Capacity Single Point Manual Release Car Lift SAE-C10A Model: C10A Manual SAE-C10A— Revision A1 — June 2024...
- Page 2 Introduction This manual is designed to help customers use Stratus C10A, 2 post lift. This is a mid rise, with an open center that provides full under vehicle access. This lift comes with a capacity of 10,000 LBS. Stratus recommends keeping this manual within reach of the lift for anyone who is to use or service the machine.
- Page 3 Liability Stratus Auto Equipment assumes no liability for damages resulting from: •Use of the product for purposes other than those described in this manual. •Modifications to the equipment without prior, written permission from Stratus Auto Equipment •Injury or death caused by modifying, disabling, overriding, or removing safety features.
- Page 4 Stratus Auto Equipment's website. Not all of Stratus Auto Equipment lift models meet the standards as prescribed by ANSI/ALI ALCTV-(current edition) or ANSI/UL 201. Consult www.autolift.org...
-
Page 5: Unit Information
Unit Information Be sure to document the Model Number, Serial Number, and Date of Manufacture from the label on your unit below. This information is required for part or warranty issues. - Page 6 Index Important Safety Instructions ............7~11 1.1 Important Notices 1.2 Qualified Personnel 1.3 Warning Signs 1.4 Safety Instructions 1.5 Labels 1.6 Sound Level 1.7 Training 1.8 Special Reminder 2. Overview of the Lift...................12 2.1 General Description 2.2 Measurements 3. Installation Instructions..............13~17 3.1 Precautions for Installation 3.3 Installation 4.
-
Page 7: Important Safety Instructions
Important Safety Instructions 1.1 Important Notices Make sure to pay careful attention to the label of the lifting capacity attached on the lift and never try to lift cars above the lifting capacity labeled. Read this manual carefully before operating the machine so as to avoid personnel injury Users are not permitted to make any modification to the control or mechanical unit 1.2 Qualified Personnel... - Page 8 1.4 Safety Instructions Make sure that you have read the User’s Manual completely, including relevant instructions on installation, operation, and safety before operating the lift. This lift is designed for lifting vehicles 10,000 LBS and under. Any other use may result in damage of the lift or injury to personnel.
- Page 9 Keep areas well lit. Keep loads balanced on the lift platforms. Clear the area immediately if a vehicle is in danger of falling off the lift. DO NOT ATTEMPT TO CATCH A FALLING VEHICLE! Make sure there are no obstacles under the vehicle before lowering it If the lift will be left unused for a long period of time, it is recommended that the user disconnects power, empties the oil tank, and lubricates any moving parts with hydraulic Attention: For environment protection, please dispose of the used oil in a proper way.
- Page 10 CAUTION Only trained personnel is allowed to use the lift. Read the entire manual before operating Never try to raize the vehicle exceding lift capacity Make sure you meet all safety requirements before you start working under the vehicle Surrounding of lift will remain clear when raising or lowering The manufacturer and distributor will not take any responsibility if user does not follow the...
- Page 11 1.6 Sound Level The sound emitted from the lift should not exceed 75 DB. 1.7 Special Reminder The newly installed lift can NOT directly lift vehicle, and should be raised to the highest point then lowered to the lowest point 2-3 times repeatedly without any load to bleed the air out from the hydraulic hose and cylinders to ensure the lift runs smoothly 1st time use of the lift with a load after bleeding air out of the the hydraulic hose and cylinders should follow the steps below...
- Page 12 Overview of the Lift 2.1 Technical data Lifting Model Lifting Time Lifting Height Power Supply Capacity 74 7/8" (1902 SAE- C10A 10,000 LBS ~50 sec 220V, 1ph 2.2 Measurements...
-
Page 13: Installation Instructions
Installation Instructions 3.1 Precautions for Installation The joints of the oil hose must be firmly connected in order to avoid leakage All bolts should be firmly screwed up Do not place any vehicle on the lift during trial running 3.2 Installation Remove the accessory packages, and take the parts out of their packaging. - Page 14 Once each post has been assembled, install the post cap for the cross beam. With the post assembled, wire the safety switch through the post Next, assemble the cross beam Symmetrical (Left image) Keep the singular rod on the ends of the crossbeam Asymmetrical (Right image) Remove the singular rod on the ends of the cross beam, and replace them with the 2 smaller provided rods, placed symmetrically on the cross beam...
- Page 15 Once the cross beam has been assembled, and the post have been stood up, install the cross beam onto the posts with the bolts provided. NOTE: The cross beam must be installed with the 3 holes on the cross beam placed on the side of the main post, and the 2 holes on the cross beam placed on the side of the secondary post.
- Page 16 Next, install the mounting bracket for the pump, and proceed to install the pump Connect the hydraulic hose from the post to the pump With the pump installed, connect the wiring and safety lock release lever...
- Page 17 With the pump installed on the main post, assemble the arms Line up the holes on the arms with the holes on the lifting carriage, and insert the pin Install the 3 stage arm in the back, and the 2 stage arm in the front of the lift.
- Page 18 If the lift is used while the vehicle’s center of gravity is not positioned midway between the rising platforms, Stratus, as well as our dealers will not bear any responsibility for any consequence resulted thereby.
-
Page 19: Frequently Asked Questions
Frequently Asked Questions What thickness of concrete do you recommend? We recommend 6-12 inches of reinforced concrete that has cured for at least 30 days. What is the recommended PSI for the concrete? We recommend a psi of 3,000 What kind of oil do I use? AW32 or AW46 hydraulic oil Does this lift come with a plug? The lift does not come with a plug, you will need to get a 110V, or 220V... -
Page 20: Maintenance
Maintenance Daily Pre-operation Check hydraulic connections and hoses for leaks Check mechanical locks audibly and visually while in operation Check arm locks Check bolts, nuts, and screws are tight Every 1 Month Check all cable connections, pins and bolts to insure proper mounting Inspect all anchor bolts and retighten if necessary Check columns for square-ness and plumb Check equalizer cable tension, adjust if necessary... -
Page 21: Warranty
Warranty 5 years lifting structure Post, Cross Bar, Carriage, Arms, Safety Locks, Safety Lock Pins, Arm Pin, Runway 3 years hydraulic Power Unit/Station, Cylinder 2 years electrical Electrical, Buttons, Solenoid, Limit Switch 1 Year Balance Cable, Safety Lock Release Cable, Safety Covers, Support Bar, Ramps, Hydraulic Hose, Fittings No Warranty Door Guard, Rubber Pads, Truck Adaptors **Parts only!! Labor costs for someone to install replacement parts are NOT covered. - Page 22 Parameters Model C10A Rated Lifting Capacity 10,000 LBS Minimum Height 3 15/16" (100 Lifting Height 74 7/8" (1902 MM) Drive Clearance 103 15/16" Front Arm Reach: Max 61 1/4" (1555 MM) Front Arm Reach: Min 39 3/8" (1000 MM) Rear Arm Reach: Max 42 5/16"...
-
Page 23: Exploded View
Exploded View Pump: Description Description Motor Oil Hose Tie-In Hydraulic Block Electrical Unloading Valve Overflow Valve Single Way Valve Fitting Gear Pump Cushion Valve Oil Tank Absorbing Oil Pipe Oil Tank Cover Oil Filer Oil Back Pipe Throttle Valve... - Page 24 Exploded View Lift: Description Description Cross beam Extension column Bolt M10x30 Bolt M10x30 Nut M10 Nut M12 Flat Washer 12 Flat washer 10 Spring Washer 10 Spring Washer 12...
- Page 25 Description Description Screw M6x10 Oil cylinder 50x38x1850 Power side safety lock Lifting carriage Power side column Pin roll Power side safety lock Three-stage lifting arm cover Bolt M8x25 Shaft ring 38 Nut M8 Two-stage lifting arm Flat Washer 8 Shaft ring 25 Spring Washer 8 Slide wheel Power Unit...
- Page 26 Exploded View Hydraulic System Description Description Oil hose 450 Oil hose 5500 Power unit fitting Hollow bolt G 1/4 Composite bush Composite gasket G 1/4 Straight angle fitting G Oil hose 5500 Oil hose 4350 Fitting 65 T fitting G 1/4...
- Page 27 Exploded View Safety lock system Description Description Shaft ring 30 Handle Safety lock hook shaft Handle turning block Lock spring cushion Off side safety lock Power side safety lock Safety cable clip M2 Torsional spring Safety cable 7300 Nut M10 Safety cable fixing plate Handle ball M10 Nut M6...
- Page 28 Exploded View Cross Beam Description Description Slide wheel 30° cross beam I Composite bush 2516 Spacer sleeve 12 Short shaft 30° cross beam junction plate Spacer Sleeve 32 Bolt M10x30 Shaft ring 25 Nut M10...
- Page 29 Description Description Flat washer 10 Locking nut M8 Spring washer 10 Bolt M6x16 Bolt M5x10 Locking nut M6 Hole plate Bolt M12x30 Nut M12 Foam sleeve Flat washer 12 Limit switch Spring washer 12 Hole plate 2 30° cross beam II Bolt M8x25 Sliding shaft...
- Page 30 Exploded View Lifting carriage Description Description 30° lifting carriage Bolt M8x20 Socket head screw Pull rod M10x16 Spring washer 10 Pressure spring Slider pressure plate Tooth piece Slider Spring pin 5x35 Door protection Shaft ring 22 plastic pad...
- Page 31 Exploded View Three Stage Arm Description Description Screw adapter Hexagon socket screw M8x10 Front arm Rear arm Oriface plate Tooth block Hexagon socket screw Socket head screw M10x20 M8x8 Middle arm Spring washer 10...
- Page 32 Exploded View Two Stage Arm Description Description Screw adapter Tooth block Front arm Hexagon socket screw M10x20 hexagon socket screw Spring washer 10 M8x10 Rear arm...
- Page 33 Automotive Lift Institute Store You probably checked the ALI’s Directory of Certified Lifts(www.autolift.org/ali-directory-of- certified-lifts/) before making your most recent Lift purchase, but did you know the ALI Store (www.autolift.org/ali-store/) offers a wide variety of professional, easy-to-use, and reasonably priced training and safety materialsthat will make your garage a safer place to work? The ALI Store is your trusted source for workplace safety! Visit today and get the training and materials you need to worksafely:...
- Page 34 Special Notes Environmental damage : Only appropriately trained personnel may dismantle and dispose of the unit. Dismantling: To dismantle the product, proceed as follows: ELECTRICAL HAZARD! When carrying out any decommissioning and dismantling work on the unit, switch off all power supply connections, ensure they cannot be switched on unintentionally and verify that they have been disconnected.
