Extraordinary maintenance
A specialist from the customer service department
should carry out a general inspection every two years
during normal use and at the end of the season in the
case of intensive use.
Unauthorized alterations or the use of non-original
accessories may lead to severe or even fatal accident
to the detriment of the user or third parties.
12. Storage
If the cultivator will not be used for a period longer than
30 days, follow the steps below to prepare your tiller for
storage.
1. Drain the fuel tank completely. Stored fuel containing
ethanol or MTBE can start to go stale in 30 days.
Stale fuel has a high plastic content and can clog the
carburetor and restrict fuel flow.
2. Start the engine and allow it to run until it stops. This
ensures no fuel is left in the carburetor. Run the en-
gine until it stops. This helps prevent plastic deposits
from forming inside the carburetor and possible en-
gine damage.
3. While the engine is still warm, drain the oil from the
engine. Refill with fresh oil of the grade recommend-
ed in the Engine Manual.
4. Allow the engine to cool. Remove the spark plug
(14a) and put 30 ml of high quality motor oil into the
cylinder. Pull the start lever (13) slowly to distribute
the oil. Replace the spark plug (14a).
m ATTENTION! Remove the spark plug (18c) and drain
all of the oil from the cylinder before attempting to start
the unit after storage.
5. Use clean cloths to clean off the outside of the tiller
and to keep the air vents free of obstructions.
m ATTENTION! Do not use strong detergents or petro-
leum based cleaners when cleaning plastic parts. Chem-
icals can damage plastics.
6. Inspect for any loose or damaged parts. Repair or
replace damaged parts and tighten loose screws,
nuts or bolts.
7. Remove the blades. Clean and apply oil to the tines
and tine shafts to prevent rusting. Mount the tines
onto the tine shafts.
8. Coat the wheel axles lightly with oil. Oil the throttle
cables and all visible moving parts. Do not remove
the engine cover.
9. Storage with steering folded in: Loosen the hexago-
nal screw (2d) and the clamping lever (2a), pull out
the steering bar (6) and place it on the machine.
10. Store your tiller in upright position in a clean, dry
building that has good ventilation.
m ATTENTION! Do not store tiller with fuel in a non-ven-
tilated area where fuel fumes may reach flame, sparks,
26 GB
 www.scheppach.com  service@scheppach.com  +(49)-08223-4002-99  +(49)-08223-4002-58
pilot lights or any ignition sources. Use only approved
fuel containers.
13. Transport
Transport by pushing
Mount the wheels as described in the "Wheels"
chapter.

14. Disposal and recycling

The device is supplied in packaging to avoid transport
damages. This packaging is raw material and can thus
be used again or can be reintegrated into the raw mate-
rial cycle.
The device and its accessories are made of different ma-
terials, such as metals and plastics.
Take defective components to special waste disposal
sites. Check with your specialist dealer or municipal ad-
ministration!

15. Troubleshooting

m ATTENTION! Before carrying out any tests rec-
ommended in the following table, the device must
always be shut off and the spark plug disconnected,
unless operation of the device is explicitly required.
If all possible causes have been checked and the
fault wasn't able to be rectified, please get in touch
with an authorized customer service centre. If a
problem occurs that is not listed in this table, please
get in touch with an authorized customer service
centre.
SERVICE INFORMATION
With this product, it is necessary to note that the fol-
lowing parts are subject to natural or usage-related
wear, or that the following parts are required as con-
sumables.
W e a r i n g Spark plug, cutters, starter cable, all
parts*
operating materials
* may not be included in the scope of supply!
m ATTENTION!
Note when sending the device to a customer service
centre:
Ensure that the device is returned free of oil and petrol
due to safety reasons!
