1. Introduction
Manufaturer:
Scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D-89335 Ichenhausen
Dear customer,
We hope your new tool brings you much enjoyment and
success.
Note:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability for
damages to the product or damages caused by the prod-
uct that occurs due to:
• Improper handling,
• Non-compliance of the operating instructions,
• Repairs by third parties, not by authorized service
technicians,
• Installation and replacement of non-original spare
parts,
• Application other than specified.
We recommend:
Read through the complete text in the operating instruc-
tions before installing and commissioning the device.
The operating instructions are intended to help the user
to become familiar with the machine and take advantage
of its application possibilities in accordance with the rec-
ommendations. The operating instructions contain im-
portant information on how to operate the machine safe-
ly, professionally and economically, how to avoid danger,
costly repairs, reduce downtimes and how to increase
reliability and service life of the machine.
In addition to the safety regulations in the operating in-
structions, you have to meet the applicable regulations
that apply for the operation of the machine in your coun-
try.
Keep the operating instructions package with the ma-
chine at all times and store it in a plastic cover to protect
it from dirt and moisture. Read the instruction manual
each time before operating the machine and carefully fol-
low its information. The machine can only be operated by
persons who were instructed concerning the operation of
the machine and who are informed about the associated
dangers. The minimum age requirement must be com-
plied with.
In addition to the safety instructions contained in this
manual and the special regulations of your country, the
technical rules generally accepted for the operation of
identical devices must be observed.
 www.scheppach.com  service@scheppach.com  +(49)-08223-4002-99  +(49)-08223-4002-58
2. Device description (Fig. 1)
1. Reverse gear
2. Forward gear
3. Throttle
4. On/off switch
5. Plastic cover
6. Steering column
7. Exhaust cover
8. Air filter cover
9. Tank cover
10. Fuel tank
11. Choke - lever
12. Fuel valve
13. Cable pull
14. Wheels
15. Cutter
16. Side guard
17. Protective guard
18. Depth limiter
3. Scope of delivery (Fig. 1+2)
2a Clamping lever (1x)
2b Hexagonal flanged screw, collar bushing, washer
and locknut (1x)
2c Fillister head flanged screw and hexagonal nut
(2x)
2d Hexagonal flanged screw and hexagonal nut (1x)
2e Wing nut (6x)
2f Tube clip (2x)
2g Hexagonal open-end spanner 17/19 (1x)
2h Hexagonal open-end spanner 13/16 (1x)
2i Hexagonal open-end spanner 12/14 (1x)
2j Hexagonal open-end spanner 8/10 (1x)
2k Screwdriver (cross-head) (1x)
2l Spark plug wrench (1x)
2m Housing with engine / gearbox and steering bar
(1x)
• Open the packaging and remove the device carefully.
• Remove the packaging material as well as the packag-
ing and transport bracing (if available).
• Check that the delivery is complete.
• Check the device and accessory parts for transport
damage. When complaints the dealer must be in-
formed immediately. Subsequent complaints will not
be accepted.
• If possible, store the packaging until the warranty peri-
od has expired.
• Read the operating instructions to make yourself famil-
iar with the device prior to using it.
• Only use original parts for accessories as well as for
wearing and spare parts. Spare parts are available
from your specialized dealer.
• Specify our part numbers as well as the type and year
of construction of the device in your orders.
