Echoflex Installation Guide
DMX Scene Controller

Accessory Kits

Echoflex offers a Low Voltage DIN rail Cover Kit (part number
8186A1218) that allows installation of the DMX Scene Controller to a
10.16 cm (4 in) junction box (provided by others). Contact Echoflex for
ordering details.

Specification

Note:
electrical equipment.
For use with Echoflex Elaho Control Systems, powered by an Elaho station
power supply.
Ambient Environment
For indoor, commercial controls use only. Supports plenum rating.
• Operating temperature 0°C–50°C, 5%–95% non-condensing
humidity.
Compliance
• UL/cUL listed, supporting use in a plenum space
• CE compliant with EN55103:2009 for professional lighting control
• WEEE marked
• FCC compliant for conducted and radiated emissions
Electrical Requirements
The DMX Scene Controller requires 24 VDC (Class 2) power, supplied by
an external 24 VDC power supply. Termination for this connection is
provided on a two-position terminal labeled 24 VDC, accepting
0.4–2.5 mm
and red wire pair).
Note:
NEC Article 725 and local jurisdiction requirements.
All power and control wiring should be installed and terminated
by a qualified installer and should follow standard wiring
installation practices.
DMX Scene Controller
Installation must follow all national and local codes for
2
(26–14 AWG) wires (typically a 1.5 mm
NEC Class 2 products are to be wired in accordance with
Page 2 of 8
2
[16 AWG] black
