Flywheel axle Spring washer Spacer bush Flange nut 3/8""-26 Bolt M6×25H Fan guard-left Adjusting bolt Fan guard-right bolt Fan guard fixed button Lock nut M8×1.25 Cross screw ST5×15H Drive sprocket Chain 12.7*100 Spacer bush ELITE VORTEX AIR BIKE ASSEMBLY MANUAL...
Page 6
PARTS LIST bushing Blocking piece Nut 3/8""-26x4.5t Spring washer Chain cover-right Screw ST4.2×19H Chain cover-left Spacer bush Front cover-left Flat washer Front cover-right bearing Screw M5×10H Lock nut screw Fixed gear wheel Circlip foam Wire protective plug Socket spanner...
Page 7
Then, affix the front stabiliser (part 4) to the main frame (part 1). Fasten it securely using flat washers (part 22), spring washers (part 21), and bolts (part 20). Use a hex wrench (part 32) to tighten them securely. ELITE VORTEX AIR BIKE ASSEMBLY MANUAL...
Page 8
ASSEMBLY INSTRUCTIONS STEP 2 Insert the handlebar (2 & 3) into the main frame (1) as shown, then screw it in clockwise and �ghten it securely using a spanner (34).
Page 9
Insert the le� handlebar (2) into the le� connec�ng bar (31), then securely �ghten the le� handlebar (2) with a flat washer (26) and nylon nut (27) using a mul�func�on spanner (33). Repeat the same process for the right handlebar (3) and right connec�ng bar (31). ELITE VORTEX AIR BIKE ASSEMBLY MANUAL...
Page 10
ASSEMBLY INSTRUCTIONS STEP 4 Securely a�ach the pedal (18), marked "L", to the crank (64), also marked "L", using a mul�func�on spanner (33) in an an�clockwise direc�on. Then, fix the pedal (19), marked "R", to the crank (65), marked "R", �ghtly in a clockwise direc�on using the mul�func�on spanner (33).
Page 11
(part 16) and bolts (part 15). Tighten them using a hex wrench (part 32). Next, securely fasten the bottle holder (part 13) onto the main frame using cross screws (part 14) and a multifunction spanner (part 33). ELITE VORTEX AIR BIKE ASSEMBLY MANUAL...
Page 12
ASSEMBLY INSTRUCTIONS STEP 6 Insert two AA ba�eries. Connect the wire on the console (9) to the sensor wire (28) securely, then firmly a�ach the console to the console support post (8) plate using cross screws (29), �ghtened with a mul�func�on spanner (33).
Page 13
Release the tension on the spring handle (part 17) and pull it out. Insert the saddle post (part 6) into the frame (part 1) and secure it by tightening the spring knob (part 17). ELITE VORTEX AIR BIKE ASSEMBLY MANUAL...
Page 14
ASSEMBLY INSTRUCTIONS STEP 8 Attach the saddle (part 10) securely to the saddle sliding set (part 7) as demonstrated, using a socket spanner (part 14). Next, loosen the knob (part 12) to adjust the saddle (part 10) to your preferred position. Once adjusted, tighten it using the same knob (part 12).
Page 15
ASSEMBLY COMPLETE CONGRATULATIONS Assembly of your Elite Vortex Air Bike Failure to visually check and test the assembly of your air bike before use can cause damage to the air bike, serious injury to users and bystanders and can also compromise the effec�veness of you exercise program.
CONSOLE USER INSTRUCTIONS Functions: • RPM: 015199. • SPEED: 0.099.9 km/h. • TIME: 1:00:001:59:59, can count up and count down. • DISTANCE: 0.00999.9 km, can count up and count down. • CALORIES: 0999, can count up and count down. • WATT: 01999. •...
• When there is heartbeat input, the heartbeat value of 85%, 65%, and maximum heartbeat value will switch display. If there is no heartbeat input, all values won’t display. • Press any PROGRAM to perform this ac�on. ELITE VORTEX AIR BIKE ASSEMBLY MANUAL...
Page 18
INSTRUCTIONS Interval: When powered on, the user can press UP/DOWN to select this func�on. In standby mode, the user can also press the INTERVAL key to enter directly. Interval 20/10: • Press INTERVAL Key to select INTERVAL 20/10. Press ENTER to enter this mode; INTERVAL 20/10 will flash, and the buzzer will sound.
Page 19
01/XX. • CYCLE TIME begins to count down, and the REST will flash every 1 second, the buzzer beeps at the same �me. At the last 3 seconds, the READY will flash. ELITE VORTEX AIR BIKE ASSEMBLY MANUAL...
INSTRUCTIONS • C and D will perform cyclically un�l displaying the se�ng value. A�er exercise, CYCLE TIME begins to count down from 10 seconds, and the REST will flash every 1 second. • If there is no signal input for 30 seconds, the buzzer will ring, then enter Sleeping mode. •...
Page 21
A�er entering STOP mode, all displays will remain on the screen for 3 seconds, then they will flash every 4seconds. • If there is no signal input for 30 seconds, the buzzer will sound, then the console will enter standby mode. ELITE VORTEX AIR BIKE ASSEMBLY MANUAL...
Page 23
EXPLODED DIAGRAM ELITE VORTEX AIR BIKE ASSEMBLY MANUAL...
Page 24
SETTING YOUR BIKE UP Saddle Height Adjustment Adjusting the Seat Fore-and-Aft Position Adjusting the Seat Fore-and-Aft Position Saddle Height Adjustment...
LIMITED WARRANTY Warranty Range Warranty Time HOME USE The following conditions are not under warranty range: Repair and Maintenance Service ELITE VORTEX AIR BIKE ASSEMBLY MANUAL...
