Adaptation packages content

Target Adaptation
Conversion boards connect between the Emulation Adapter and the matching Solder part which is
being soldered on the Target side.
Pin number
64
80
100
144
Fixed Adaptation
The adaptation is elivered with a slot screw, which can be used to achieve a more solid and stable
fixing of the Conversion board and the Solder part.
Conversion board
Flex Adaptation with Wire adapter
This part provides a flexible connection of the Emulation Adapter to the Solder part as an
alternative to the fixed connection.
Conversion board
Conversion board
IEA-CYT2B9-ATQ64
IEA-CYT2B9-ATQ64W
IEA-CYT2B9-ATQ80
IEA-CYT2B9-ATQ80W
IEA-CYT2B9-TQ100
IEA-CYT2B9-TQ144
Type
Fixed
Flex
Fixed
Flex
Fixed
Fixed
Solder part
Solder part
www.tasking.com
Solder part
IA64ATQ-SOLDER
IA64ATQ-SOLDER
IA80ATQ-SOLDER
IA80ATQ-SOLDER
IA100TQ-SOLDER
IA144TQ-SOLDER
