Solder parts
In the case of soldering the Solder part manually, it's highly recommended to prolong the solder
pad E on the outer side (e.g., for 1.5–2 mm) during the PCB design. Note that without this
modification, it's very difficult to solder the Solder part manually.
Recommended PCB footprint dimensions:
Ordering code
A
IA64ATQ-
12
SOLDER
IA80ATQ-
14
SOLDER
IA100TQ-
16.5
SOLDER
IA144TQ-
22
SOLDER
Use the Surface Mount Technology (SMT) to solder the Solder parts to the user target
board instead of the original microcontroller. iSYSTEM provides this soldering service on
request too.
Emulation Adapter
Ordering code
M
IEA-CYT2B9 70
IEA-CYT2B9-
xxxxx
To view Emulation Adapter schematics, use the short link isystem.com/schematics.
B C
1.505 13.0
1.505 15.0
1.125 17.0
1.125 23.0
N P
70
70
Unit (mm)
D E
13.0 2.3
15.0 2.3
17.0 2.15
23.0 2.15
Unit (mm)
R S
32.6
70
K L
14 14
16.0 16
19.55 19.55
25.05 25.05
T V
38 47.5
