- Page 1 ‘ 2511N Zone Commander Ripper Models: 3, 4, 5 Shanks Operator’s Manual FOR MODELS BEFORE 04/15/2024 SEE F-1011 RIGID & FOLDING IN-ROW RIPPER LANDOLL COMPANY, LLC 1900 North Street Marysville, Kansas 66508 (785) 562-5381 800-428-5655 ~ WWW.LANDOLL.COM F-1172-2409...
- Page 2 Landoll Company, LLC Marysville, Kansas www.landoll.com MODEL # SERIAL # MADE IN USA 1-573-010006 Data Plate and Location Manuals for 2511N Zone Commander Ripper - 3, 4, 5 Shanks Manual Number Manual Type F-1172 Operator’s Manual F-1171 Parts Manual...
- Page 3 DANGER DO NOT operate or perform any maintenance tasks on this equipment until you have completed the following: 1. Receive proper training to operate this equipment safely. 2. Read and understand the operator’s manual. 3. Be thoroughly trained on inspection and repair procedures. Failure to comply with this warning may result in serious injury or possibly death.
- Page 5 Table of Contents Introduction and Safety Information Introduction ............1-2 Using this Manual .
- Page 6 TABLE OF CONTENTS Lubrication ............4-4 Storage .
-
Page 7: Parts Manual
Introduction and Safety Information The Landoll Model 2511N Zone Commander Ripper is a quality product designed to give years of trouble free performance. By following each section of this manual, your system will perform as designed for you and your operation. -
Page 8: Introduction And Safety Information
Proper assembly and Model Number available when ordering parts from your maintenance will provide you with satisfactory use for Landoll dealer. If items covered in this manual are not seasons to come. understood, contact your local Landoll dealer. -
Page 9: Transporting Safety
TABLE OF CONTENTS INTRODUCTION AND SAFETY INFORMATION Safety • When applying decals to the implement, be sure to clean the surface to remove any dirt or residue. Where possible, sign placement should protect the NOTE sign from abrasion, damage, or obstruction from mud, dirt, oil etc. -
Page 10: Attaching, Detaching, And Storage
TABLE OF CONTENTS INTRODUCTION AND SAFETY INFORMATION Attaching, Detaching, and Prepare for Emergencies Storage 1. Keep a First Aid Kit and Fire Extinguisher handy. 2. Keep emergency numbers for doctor, ambulance, 1. Do not stand between the tractor and implement hospital and fire department near the phone. -
Page 11: Model Specifications
9' 3" 3,230 LBS. 2511N-4-30 30" NONE 9' 3" 3,825 LBS. 2511N-5-30 30" 12" BOLT-ON 12' 0" 4,715 LBS. 2511N Zone Commander Ripper - Rigid Shear Bolt Models Model Number of Shank Transport Estimated Shank Spacing Number Shanks Extensions Width Weight 2511N-3-30 30"... -
Page 12: Standard Specifications
TABLE OF CONTENTS STANDARD SPECIFICATIONS General Torque Specifications (rev. 4/97) TORQUE SPECIFIED IN FOOT POUNDS - This chart provides tightening torques for general purpose applications when special torques are not specified on process or drawing. Assembly torques apply to plated nuts and capscrews assembled without supplemental lubrication (as received condition). -
Page 13: Hydraulic Fitting Torque Specifications
TABLE OF CONTENTS STANDARD SPECIFICATIONS Hydraulic Fitting Torque Specifications TORQUE IS SPECIFIED IN FOOT POUNDS- 37 JIC, ORS, & ORB (REV. 10/97) This chart provides tightening torques for general purpose applications when special torques are not specified on process or drawing. Assembly torques apply to plated nuts and capscrews assembled without supplemental lubrication (as received condition). - Page 14 TABLE OF CONTENTS STANDARD SPECIFICATIONS Shank Placement Dimensions 110-3/8 44-1/4 Figure 2-1: 2511N-3-30 Shank and Lighting Placement F-1172-2409...
- Page 15 TABLE OF CONTENTS STANDARD SPECIFICATIONS 110-3/8 44-1/4 Figure 2-2: 2511N-4-30 Shank and Lighting Placement F-1172-2409...
- Page 16 TABLE OF CONTENTS STANDARD SPECIFICATIONS 139-3/4 44-1/4 Figure 2-3: 2511N-5-30 Shank and Lighting Placement F-1172-2409...
- Page 17 Chapter 3 TABLE OF CONTENTS Assembly Instructions It is very important that your new 2511N Zone DANGER DANGER Commander Ripper be properly assembled, adjusted, and lubricated before use. Illustrations are provided in this In the event a shank trips and does not release, section to show proper assembly procedures.
-
Page 18: Assembly Preparation
TABLE OF CONTENTS ASSEMBLY INSTRUCTIONS Assembly Preparation SMV Bracket Installation 1. Hook up the Ripper to a tractor using the 3-PT Hitch. 1. Attach the SMV Mounting Bracket at a point where emblem is visible from rear of machine, using U-Bolt 2. -
Page 19: Shank Assembly
The RSB Clamp has three holes: the top hole has a maximum operating depth up to 14", the lower two holes have operating depths ranging from 16" to 20". Landoll recommends using the top upper holes for optimal machine efficiency. WARNING... - Page 20 TABLE OF CONTENTS ASSEMBLY INSTRUCTIONS DANGER OPERATING AT A DEPTH THAT EXCEEDS THE MAXIMUM SHANK TRIP HEIGHT EXPOSES THIS MACHINE TO DAMAGE THAT MAY LEAD TO PERSONAL INJURY OR DEATH. TORQUE THE GATE AUTO RESET CLAMP BOLTS TO SPRING CLAMP 300-400 FT/LBS 171811 The Auto Reset...
- Page 21 TABLE OF CONTENTS ASSEMBLY INSTRUCTIONS RSB CLAMP WELDMENT 171811 COVERBOARD KIT (OPTIONAL) CONNEX BUSHING WEARSTRIP BRACKET SHANK LEG WEARSTRIP SHOWN: 1-1/4 Parabolic 224746 SPRING SLOTTED PINS MULTIPLE POINTS AVAILABLE SEE PARTS MANUAL FOR DETAILS Figure 3-2: RSB Shank Clamp F-1172-2409...
-
Page 22: Bolt,1/4-20
TABLE OF CONTENTS ASSEMBLY INSTRUCTIONS Coverboard Installation 1. Insert four 1/2-13 x 2-1/2 Bolts into the Coverboard Bracket before attaching the Coverboard Furrower. See Figure . Secure with 1/2-13 Locknuts and tighten only so that locking portion of nut engages the thread. -
Page 23: U-Bolt,5/8
TABLE OF CONTENTS ASSEMBLY INSTRUCTIONS Coulter Assemblies - Right 2. Install the Coulter Adjustment Tube and Coulter Assembly to the frame using the Coulter Clamp Tube, Hand and Left Hand U-Bolts, Clamp Plate and 5/8-11 Locknuts. Do not tighten nuts until the depth adjustment is completed. 1. - Page 24 TABLE OF CONTENTS ASSEMBLY INSTRUCTIONS Table provided for general use. NOTES: F-1172-2409...
- Page 25 TABLE OF CONTENTS ASSEMBLY INSTRUCTIONS Warning Lamps Installation FOR 5 SHANK MODELS: 1. Attach left and right Amber Light Mount Brackets to the existing bolt in Coulter Clamp Plate. NOTE Figure 3-4. Be sure when assembling Lamps onto Bracket that the 2.
-
Page 26: Table Of Contents
TABLE OF CONTENTS ASSEMBLY INSTRUCTIONS Screw,1/4-20 x 1-1/4 Light Mount Red Lamp Bracket w/ Reflectors Flange Nut,5/8-11 Screw, 1/4-20 x 1-1/4 Screw,1/4-20 x 1-1/2 Light Tail Mount Bracket Light Mount Bracket AG Flasher Control Module Locknut, 3/4-10 7-Pin/4-Pin Harness Rear Warning Amber Lights Harness Lamp... -
Page 27: Smv Mounting Bracket
TABLE OF CONTENTS ASSEMBLY INSTRUCTIONS Screw,1/4-20 x 1-1/4 Amber Light Mount Bracket Lamp w/ Reflectors Screw, Light Mount 1/4-20 x 1-1/2 Bracket Screw,1/4-20 x 1-1/4 Locknut, 3/4-10 Red Lamp 7-Pin/4-Pin Light Tail Mount Harness Rear Warning Bracket Lights Harness Bolt,1/4-20 x 3/4 Locknut,1/4-20 Light Mount Reflector Bracket... - Page 28 TABLE OF CONTENTS ASSEMBLY INSTRUCTIONS 7-PIN 4-PIN CIRCUIT WIRE COLOR CONN. TOWER GROUND GROUND – WORK LAMPS BLACK LEFT FLASHING YELLOW & TURN – STOP LAMPS RIGHT FLASHING GREEN & TURN TAIL LAMPS BROWN SWITCHED – BLUE POWER (12 V) LED WARNING LIGHT HARNESS - WIRING CHART 2-PIN 3-PIN...
- Page 29 TABLE OF CONTENTS ASSEMBLY INSTRUCTIONS Finishing Features - Optional The Closer Platform offers 6 different mounting features: Closer Wheel, Flat Bar Basket 20", Closer Disc, Crumbler Closer Wheel, Packer Reel or Treader. See Figure 3-1. Platform Mount AFTER ALWAYS REPLACE PARTS WITH UPDATED 04/2024 CLOSER PLATFORM.
- Page 30 TABLE OF CONTENTS ASSEMBLY INSTRUCTIONS • To increase the down pressure, place both Spacer/Bushing spacers between the Rear Spring Keeper and the Slide Bushing. Retaining Washer Locknuts • To decrease the down pressure, place both Slide Bushing spacers between the Retaining Washer and the Spacer/Bushing Locknuts.
- Page 31 Chapter 4 TABLE OF CONTENTS Operation and Maintenance DANGER DANGER WARNING Coulter blades are sharp. Do not allow coulters to All hydraulically elevated equipment must be roll over or fall on any part of the body. Do not locked out or lowered to the ground when allow wrenches to slip when working near coulter servicing or when equipment is idle, to prevent blades.
-
Page 32: Operation And Maintenance
Tractor Preparation Attaching to 3-PT Hitch 1. Carefully back the tractor into place. The 2511N Rigid Zone Commander Ripper may be used on tractors equipped with Category 2 or 3N 3-PT Hitches. 2. Attach the Ripper to the tractor. Before attaching the Ripper, prepare the tractor as 3. -
Page 33: Wheel Bearing Maintenance
TABLE OF CONTENTS OPERATION AND MAINTENANCE Field Operation - 3-PT Hitch Wheel Bearing Maintenance 1. Lower the Ripper to the ground and pull it a few feet Check wheel bearings and coulter bearings occasionally at the approximate desired depth. for excessive end play. To correctly replace the wheel bearings: 2. - Page 34 TABLE OF CONTENTS OPERATION AND MAINTENANCE Lubrication When lubricating the machine, SAE multi-purpose EP grease, or EP grease with 3-5% molybdenum sulfide is recommended. Wipe soil from fittings before greasing. Replace any lost or broken fittings immediately. • Grease Coulter Hub and Swivel Mount Casting after 20 hours of use.
- Page 35 Troubleshooting The Troubleshooting Guide, shown below, is included to help you quickly locate problems that can happen using your 2511N Zone Commander Ripper. Follow all safety precautions stated in the previous sections when making any adjustments to your machine. PROBLEM...
-
Page 36: Troubleshooting
TABLE OF CONTENTS TROUBLESHOOTING Table provided for general use. NOTES: F-1172-2409... - Page 37 Landoll Company, LLC Warranty Department within ten (10) days of the first retail sale. As stated above, Landoll Company, LLC Warranty Staff will identify components listed on a Warranty Claim required to be returned for further analysis. All parts returned to Landoll Company, LLC must be shipped with a Return Materials Authorization (RMA) provided by the Landoll Company, LLC Warranty Staff.
-
Page 38: Warranty
This exclusive remedy shall not be deemed to have failed of its essential purpose so long as Landoll Company, LLC is willing and able to repair or replace defective parts in the prescribed manner. - Page 39 TABLE OF CONTENTS WARRANTY Table provided for general use. NOTES:...
-
Page 40: Instructions For Ordering Parts
Landoll Company, LLC Marysville, Kansas www.landoll.com MODEL # SERIAL # MADE IN USA 1-573-010006 Data Plate and Location Manuals for 2511N Zone Commander Ripper - 3, 4, 5 Shanks Manual Number Manual Type F-1172 Operator’s Manual F-1171 Parts Manual... - Page 41 Document Control Revision Log: Date Form # Improvement(s): Description and Comments 09/2024 F-1172-2409 Initial Release - Manual for 2511N Narrow Models Only - 3, 4, 5 Shanks...
- Page 42 Equipment from Landoll Company, LLC is built to exacting standards ensured by ISO 9001:2015 registration at all Landoll manufacturing facilities. 2511N Zone Commander Ripper Models: 3, 4, 5 Shanks Operator’s Manual FOR MODELS BEFORE 04/15/2024 SEE F-1010 RIGID & FOLDING IN-ROW RIPPER...
